Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 203
8.8 Fuel Line Hose Connection - Deutz D2.9L
Index
No.
Skyjack
Part No.
Qty. Description
A 164970 1 FUEL SYSTEM ASSEMBLY - Deutz D2.9L (S/N 95,000,967 & below)
B 169761 1 FUEL SYSTEM ASSEMBLY - Deutz D2.9L (S/N 95,000,968 & above)
1 163509 48” • HOSE, Fuel line (1/2” ID), A
58” • HOSE, Fuel line (1/2” ID), B
2 166737 113” • HOSE, Fuel line (3/8” ID)
3 102984 80” • HOSE, Fuel line (5/16” ID)
4 163521 10 • CLAMP, Gear (#10)
5 163222 3 • FITTING, Fuel hose
6 164977 1 • FITTING, Fuel line (3/8”)
7 101297 2 • BOLT, Hex head (3/8” x 1.25”, grade 5)
8 103472 2 • WASHER, Flat (3/8”), A
8 • WASHER, Flat (3/8”), B
9 104694 4 • WASHER, Flat (#10-32), A
8 • WASHER, Flat (#10-32), B
10 104606 2 • NUT, Lock nylon (3/8”-16, grade 5), A
4 • NUT, Lock nylon (3/8”-16, grade 5), B
11 300450 4 • NUT, Machine (#10-32)
12 104698 4 • BOLT, Machine (#10-32 x 0.75”)
13 164943 1 • BRACKET, Fuel assembly, A
169678 1 • BRACKET, Fuel prefilter, B
14 115745 2 • BOLT, Metric (M10-1.5 x 30mm), A
103870 2 • BOLT, Hex head (3/8” x 1.50”, grade 5), B
15 130884 2 • WASHER, Lock (M10), A
600315 2 • WASHER, Flat (M10), B
16 133319 1 • CLAMP, Cushioned loop (#18)
