Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 209
8.11 Fuel Line Hose Connection - Kubota WG2503 Dual Fuel Engine
Index
No.
Skyjack
Part No.
Qty. Description
- 171199 - FUEL LINE ASSEMBLY - Kubota WG2503 Dual Fuel
1 169678 1 • BRACKET, Fuel prefilter
2 101297 2 • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
3 103862 2 • BOLT, Hex head (0.25”-20 x 2.25” Grade 5)
4 104606 1 • BOLT, Hex head (0.25”-20 x 0.75” Grade 5)
5 104606 2 • NUT, Hex head nylon lock (0.375”-16 gr 5)
6 115649 3 • NUT, Hex head nylon lock (0.25”-20 gr 5)
7 103472 4 • WASHER, Flat (0.375”)
8 103995 6 • WASHER, Flat (0.25”)
9 170571 2 • QUICK CONNECT, Stem (8mm tube, SAE #3)
10 124433 2 • CLAMP, Loop cushioned (2” dia)
11 170572 2 • QUICK CONNECT, Stem (8mm tube, SAE #6)
12 142397 5 • QUICK CONNECT, Straight
13 142398 3 • QUICK CONNECT, 90° elbow
14 103321 10 • CLAMP, Gear
15 142405 8” • HOSE, Fuel line (5/16 EP SAE 30R9)
16 142405 22” • HOSE, Fuel line (5/16 EP SAE 30R9)
17 142405 14” • HOSE, Fuel line (5/16 EP SAE 30R9)
18 142405 24” • HOSE, Fuel line (5/16 EP SAE 30R9)
19 142405 64” • HOSE, Fuel line (5/16 EP SAE 30R9)
20 164881 1 PUMP, Fuel
21 164883 1 MANIFOLD, Fuel pressure
22 136118 1 FILTER, Fuel
AB
