SKYJACK, Page 21
1.7 Platform Control Console (continued)
AD
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
16 153815 1 • CONTROLLER MODULE, OCM, A, C, D
170005 1 • CONTROLLER MODULE, SCM, B
17 (Ref.) - • TERMINAL STRIP, Platform
(For components, refer to Section 1.11)
18 138749 5 • SOCKET, Automotive relay, A, D
7 • SOCKET, Automotive relay, B, C
19 127131 4 • RELAY, 12V (40 AMP), A, D
7 • RELAY, 12V (40 AMP), B, C
20 138751 2 • HOUSING, Open bottom 24 pin levered
21 138756 1 • SOCKET, 24 Pin spring (16A)
22 138755 1 • PLUG, 24 Pin spring (16A)
23 103057 1 • BEEPER, 4-28VDC Slow pulsing
24 138765 8 • NUT, Hex lock (#8-32 Grade 5, nylon)
25 103957 8 • SCREW, Round head machine (#8-32 x 1/2”)
26 115545 2 • SCREW, Round head machine (#10-32 x 3/8”)
27 300450 2 • NUT, Hex lock (#10-32 Grade 5, nylon)
28 115649 4 • NUT, Hex lock (1/4”-20 Grade 5, nylon)
29 103860 4 • BOLT, Hex head (1/4”-20 x 1 3/4” Grade 5)
30 163241 4 • SLEEVE, Anti-vibration mount
31 104694 2 • WASHER, Flat (#10)
32 104003 2 • NUT, Hex head (#10-32)
33 103855 2 • BOLT, Hex head (1/4”-20 x 1/2” Grade 5)
34 103995 2 • WASHER, Flat (1/4”)
35 144264 2 • PLUG (9/32”)
36 139128 1 • PLUG (0.88”), A, D
37 131938 1 • PLUG (1 1/8”), A, D
38 103036 1 • CONNECTOR, Strain relief (1/2”)
39 116266 1 • CONNECTOR, Strain relief (PG21)
40 149402 1 • HANDREST
41 144387 1 • ALARM, Overload, B, C
42 (Ref.) 1 • LABEL ASSEMBLY, Platform controls
(For components, refer to Section 10.2)
43
103856 4 BOLT, Hex head (1/4”-20 x 0.75”, Grade 5)
44 103995 8 WASHER, Flat (1/4”)
45 115649 4 NUT, Hex lock (1/4”-20 Grade 5, nylon)
