Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 225
9.11 Oil Cooler Assembly (No Generator) - 51AJ
Index
No.
Skyjack
Part No.
Qty. Description
- 167812 1 OIL COOLER ASSEMBLY (No Generator) (51AJ)
- 167814 1 • OIL COOLER ASSEMBLY
1 160800 1 • • OIL COOLER, 12V DC
2 166788 1 • • MOUNT, Cooler bracket
3 167817 1 • • MOUNT, Oil cooler LH
4 167816 1 • • MOUNT, Oil cooler RH
5 106447 2 • • BOLT, Hex head (0.50”-13 x 2.25” Grade 8)
6 703284 1 • • FITTING, Elbow 90° (12 JICM - 12 JICFSW)
7 139007 2 • • BOLT, Hex head (0.50”-13 x 2.00” Grade 8)
8 105445 2 • • FITTING, Elbow 90° (12 JICM - 12 ORBM)
9 103870 4 • • BOLT, Hex head (0.375”-16 x 1.50” Grade 5)
10 101297 4 • • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
11 702507 4 • • NUT, Hex head nylon lock (0.50”-13 Grade 5)
12 104606 8 • • NUT, Hex head nylon lock (0.375”-16 Grade 5)
13 104379 8 • • WASHER, Flat hardened (0.50”)
14 103472 16 • • WASHER, Flat (0.375”)
15 (Ref.) 1 • DRIVE/SYSTEM PUMP
(For components, refer to Section 7.6)
16 (Ref.) 1 • OIL COOLER HOSE KIT
(For components, refer to Section 9.12)
17 (Ref.) 1 • OIL COOLER WIRING (not shown)
(For components, refer to Section 9.13)
18 703284 1 • FITTING, Elbow 90° (12 JICM - 12 JICFSW)
19 112366 1 • FITTING, Elbow 90° (08 JICM - 12 ORBM)
20 162293 1 • PAD, Guide (5.00” x 2.00” x 0.625”)
21 101297 2 • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
22 103472 2 • WASHER, Flat (0.375”)
23 144238 2 • NUT, Torque lock (0.375”-16 Grade C)
24 170451 1 • SHROUD, Upper
25 170450 1 • SHROUD, Lower
26 137625 45” • SEAL, Bulb
27 101632 4 • BOLT, Hex head (0.375”-16 x 0.75” Grade 5)
28 127067 4 • WASHER, Flat BB style (0.375”)
29 138981 1 • FITTING, Elbow 90° (10 JICM - 12 ORBM)
AB
