Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 229
9.13 Oil Cooler Wiring
Index
No.
Skyjack
Part No.
Qty. Description
- 152418 1 OIL COOLER WIRING
1 163087 1 • WIRE ASSEMBLY (Cooler relay)
2 152419 1 • HARNESS, Cooler fan
117597 1 • • CONNECTOR, Plug (2-pin)
117599 1 • • CONNECTOR, Plug wedge (2-pin)
117593 2 • • CONNECTOR, Contact socket (14/16)
3 144074 1 • HARNESS, Oil cooler
4 121504 1 • • FUSE, 20 AMP
5 119293 1 • • FUSE Holder with cover
6 152420 1 • HARNESS, Cooler temperature sensor
117596 1 • • CONNECTOR, Receptacle (2-pin)
117598 1 • • CONNECTOR, Receptacle wedge (2-pin)
117590 1 • • CONNECTOR, Contact pin (16/18)
7 117326 1 • BREAKER, Circuit (20 AMP)
8 127131 1 • RELAY, 12V (40AMP)
9 116266 1 • CONNECTOR, Strain relief
L 144193 1 • LABEL, Relay - cooler 86CR
