Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 23
1.8 Boom / Turret Controller Assembly (Dual Axis)
Index
No.
Skyjack
Part No.
Qty. Description
- 138225 1 BOOM / TURRET CONTROLLER ASSEMBLY (DUAL AXIS)
1 141326 1 • CAP, Rubber
2 141327 2 • GASKET
3 141325 1 • KIT, Handle
4 141328 4 • NUT
5 141329 4 • SCREW
6 141331 2 • SCREW, Set
7 141330 1 • COUPLING, (10 mm)
8 141313 1 • BOOT
9 141323 1 • WASHER, Retainer
10 141315 1 • SHOE, Spring
11 141321 4 • SCREW, Mounting (M4)
12 141316 1 • CAN, Enclosure
13 141320 1 • GROMMET, Rubber
14 141317 1 • GASKET, Mounting
15 141319 4 • SCREW
16 141318 1 • O-RING
17 141324 1 • SPRING, Compression
18 141322 1 • CLIP, Retainer
