Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 233
9.14 Generator & Oil Cooler Assembly - 3.5kW (46AJ) (continued)
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
34 168622 1 • SHROUD, Generator - lower, A
170451 1 • SHROUD, Generator - lower, B
35 168619 1 • SHROUD, Generator - upper, A
170450 1 • SHROUD, Generator - upper, B
36 101632 4 • BOLT, Hex head (0.375”-16 x 0.75” Grade 5)
37 137625 62” • SEAL, Bulb, A
137625 60” • SEAL, Bulb, B
38 136665 1 • BOLT, Hex head (M10 x 1.25 x 35mm Grade 8.8)
39 144260 1 • NUT, Hex head nylon lock (M10-1.25 Grade 8.8)
40 103472 4 • WASHER, Flat (0.375”), A
127067 4 • WASHER, Flat BB style (0.375”), B
41 138981 1 • FITTING, Elbow 90° (08 JICM - 12 ORBM)
L 117390 1 • LABEL, Push to reset generator
AB
