Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 235
9.15 Generator & Oil Cooler Assembly - 3.5kW (51AJ)
Index
No.
Skyjack
Part No.
Qty. Description
- 167813 1 GENERATOR & OIL COOLER ASSEMBLY - 3.5kW (51AJ CE)
1 (Ref.) 1 • GENERATOR (3.5kW - 60Hz AC)
(For components, refer to Section 9.18)
2 (Ref.) 1 • DRIVE/SYSTEM PUMP
(For components, refer to Section 7.6)
3 (Ref.) 1 • GENERATOR WIRING - 3.5kW (not shown)
(For components, refer to Section 9.17)
- 167814 1 • OIL COOLER ASSEMBLY
4 160800 1 • • OIL COOLER, 12V DC
169245 1 • • • THERMOSTAT, Oil cooler
5 166788 1 • • MOUNT, Oil Cooler angle
6 167817 1 • • MOUNT, Oil Cooler LH
7 167816 1 • • MOUNT, Oil Cooler RH
8 106447 2 • • BOLT, Hex head (0.50”-13 x 2.25” Grade 8)
9 703284 1 • • FITTING, Elbow 90° (12 JICM -12 JICFSW)
10 139007 2 • • BOLT, Hex head (0.50”-13 x 2.00” Grade 8)
11 105445 2 • • FITTING, Elbow 90° (12 JICM - 12 ORBM)
12 103870 4 • • BOLT, Hex head (0.375”-16 x 1.50” Grade 5)
13 101297 4 • • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
14 702507 4 • • NUT, Hex head nylon lock (0.50”-13 Grade 5)
15 104606 8 • • NUT, Hex head nylon lock (0.375”-16 Grade 5)
16 104379 8 • • WASHER, Flat hardened (0.50”)
17 103472 16 • • WASHER, Flat (0.375”)
18 (Ref.) 1 • OIL COOLER WIRING (not shown)
(For components, refer to Section 9.13)
19 (Ref.) 1 • GENERATOR HOSE KIT
(For components, refer to Section 9.16)
20 (Ref.) 1 • UPPER CONTRL BOX WIRING - 3.5kW generator (not shown)
(For components, refer to Section 9.17)
21 152593 1 • PAD, Wear (5.00” X 4.00” X 3.329”)
22 166735 1 • PLATE, Generator mount
23 135061 1 • FITTING, Branch tee (08 JICM - 08 JICM - 08 ORBM)
24 110498 1 • FITTING, Straight (08 JICM - 06 ORBM)
25 703412 1 • FITTING, Straight (12 JICF - 08 JICM)
26 703284 1 • FITTING, Elbow 90° (12 JICM -12 JICFSW)
27 106049 2 • BOLT, Carriage (0.313”-18 x 1.25” Grade 5)
28 103996
2 • WASHER, Flat (0.312”)
29 103984 2 • NUT, Hex head nylon lock (0.313”-18 Grade 5)
30 103472 9 • WASHER, Flat (0.375”)
31 103870 4 • BOLT, Hex head (0.375”-16 x 1.50” Grade 5)
32 112366 1 • FITTING, Elbow 90° (08 JICM - 12 ORBM)
33 103596 4 • BOLT, Hex head (0.375”-16 x 2.00” Grade 5)
34 703413 1 • FITTING, Tee (12 JICM - 12 JICM - 12 JICFSW)
Parts list continued on the following page.
