Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 239
9.16 Hydraulic Hose Connection - 3.5kW Generator & Oil Cooler
Index
No.
Hose
P/N
From To
Description Port Port Description
- 166734 3.5kW GENERATOR & OIL
COOLER HOSE KIT (46AJ
ANSI/CSA & CE)
1 H5406 0037 0 Generator (Case Drain) - T4 Hydraulic Tank
2 H5408 0053 0 Oil Cooler IN - Generator (Return)
3 H5208 0050 0 Pressure Filter OUT P2 Generator Manifold (Pressure)
4 H5408 0061 0 Generator Manifold (Auxiliary) P3 P Main Manifold
5 H5412 0027 0 Oil Cooler OUT IN Return Filter (Hydraulic Tank)
6 H5112 0067 0 Oil Cooler IN T1 Main Manifold
7 H5410 0039 0 Pressure Filter IN - System Pump
- 167841 3.5kW GENERATOR & OIL
COOLER HOSE KIT (51AJ CE)
1 H5406 0037 0 Generator (Case Drain) - T4 Hydraulic Tank
2 H5408 0036 0 Oil Cooler IN - Generator (Return)
3 H5208 0050 0 Pressure Filter OUT P2 Generator Manifold (Pressure)
4 H5408 0061 0 Generator Manifold (Auxiliary) P3 P Main Manifold
5 H5412 0100 0 Oil Cooler OUT IN Return Filter (Hydraulic Tank)
6 H5112 0135 0 Oil Cooler IN T1 Main Manifold
7 H5410 0039 0 Pressure Filter IN - System Pump
AB
