Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 247
9.21 Generator & Oil Cooler - 12kW
Index
No.
Skyjack
Part No.
Qty. Description
- 166842 1 12KW GENERATOR AND OIL COOLER ASSEMBLY (46AJ ANSI/CSA)
1 103868 2 • BOLT, Hex head (0.312”-18 x 3.50” Grade 5)
2 101297 4 • BOLT, Hex head (0.375”-16 x 1.25” Grade 5)
3 103870 4 • BOLT, Hex head (0.375”-16 x 1.50” Grade 5)
4 139007 2 • BOLT, Hex head (0.50”-13 x 2.00” Grade 8)
5 106447 2 • BOLT, Hex head (0.50”-13 x 2.25” Grade 8)
6 160800 1 • COOLER, Hydraulic oil 12VDC
7 135091 1 • FITTING, Elbow 90° (10 JICM - 10 ORBM)
8 138981 2 • FITTING, Elbow 90° (10 JICM - 12 ORBM)
9 703284 2 • FITTING, Elbow 90° (12 JICM -12 JICFSW)
10 105445 2 • FITTING, Elbow 90° (12 JICM - 12 ORBM)
11 135061 1 • FITTING, Branch Tee (08 JICM - 08 JICM - 08 ORBM)
12 166843 1 • FITTING, Run Tee (12 JICM - 10 ORBM - 12 JICM)
13 103071 1 • FITTING, Straight (08 JICM - 10 ORBM)
14 137630 3 • FITTING, Straight (10 JICM - 10 ORBM)
15 (Ref.) 1 • GENERATOR, Hydraulic, 12KVA, 11cc
(For components, refer to Section 9.19)
16 166788 1 • MOUNT, Cooler angle
17 166789 1 • MOUNT, Generator LH
18 166787 1 • MOUNT, Generator RH
19 103984 2 • NUT, Hex head nylon lock (0.313”-18 Grade 5)
20 104606 6 • NUT, Hex head nylon lock (0.375”-16 Grade 5)
21 702507 4 • NUT, Hex head nylon lock (0.500”-13 Grade 5)
22 166797 1 • PLATE, Manifold mount
23 166796 1 • PLATE, Manifold spacer
24 103996 4 • WASHER, Flat (0.312”)
25 103472 19 • WASHER, Flat (0.375”)
26 104379 8 • WASHER, Flat hardened (0.5”)
27 136665 1 • BOLT, Hex head (M10 x 1.25 x 35mm Grade 8.8)
28 144260 1 • NUT, Hex head nylon lock (M10-1.25 Grade 8.8)
29 103473 4 • BOLT, Hex head (0.375”-16 x 1.00 Grade 5)
30 137625 11” • SEAL, Bulb
31 169141
1 • COVER, Cooler
32 169526 1 • MANIFOLD, Welder generator
168448 1 • • VALVE, Spool
168059 1 • • VALVE, Check
169407 1 • • VALVE, Flow control
169408 2 • • VALVE, Relief
169409 1 • • VALVE, Relief
33 121250 3 • FITTING, Plug hollow hex (04 ORBM)
To Next Page
