Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 25
1.9 Drive / Steer Controller Assembly (Single Axis)
Index
No.
Skyjack
Part No.
Qty. Description
- 138224 1 DRIVE / STEER CONTROLLER ASSEMBLY (SINGLE AXIS)
1 141338 1 • KIT, Handle
2 141328 4 • NUT
3 141329 4 • SCREW
4 141342 2 • MICROSWITCH
5 141331 2 • SCREW, Set
6 141343 1 • COUPLING, (8 MM)
7 141339 1 • CAP, Rubber
8 141340 1 • ROCKER
9 141341 1 • ROCKER, Axel
10 141327 2 • GASKET
11 141334 1 • BOOT ASSEMBLY, Standard
12 141336 2 • SCREW Mounting
13 141335 2 • WASHER, Mounting
14 141333 1 • ENCLOSURE
15 141337 1 • SCREW, Enclosure
