Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 253
9.24 Hydraulic Hose Connections - 12 kW Generator & Oil Cooler
Index
No.
Hose
P/N
From To
Description Port Port Description
- 166799 12 kW GENERATOR & OIL COOLER HOSE KIT (46AJ ANSI/CSA)
1 H5412 0036 0 Generator Manifold T1 IN Oil Cooler
2 H5412 0096 0 Return Filter - OUT Oil Cooler
3 H5112 0115 0 Generator Manifold MAIN P Main Manifold
4 H5410 0066 0 Generator Manifold TM - Generator (Return)
5 H5410 0062 0 Generator Manifold M1 - Generator (Pressure)
6 H5408 0061 0 Hydraulic Tank T4 - Generator (Case Drain)
7 H5410 0039 0 System Pump - IN Pressure Filter
8 H5410 0045 0 Generator Manifold P1 OUT Pressure Filter
9 H5110 0053 0 Generator Manifold P2 - System Pump
10 H5208 0046 0 Generator Manifold T1 T1 Main Manifold
