Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 265
9.29 Platform Control Box Cover
AC
Index
No.
Skyjack
Part No.
Qty. Description
- 159855 - CONTROL BOX COVER
- 159863 1 • COVER ASSEMBLY, Control box
1 159907 1 • • COVER, Control box
2 105621 2 • • SCREW, Round machine (#10-32 x 1”)
3 300450 5 • • NUT, Hex lock (#10-32 Grade 5, nylon)
4 104694 5 • • WASHER, Flat (#10)
5 154305 2 • • BUSHING, Flanged (1/4” ID x 3/16”)
6 137653 1 • • HANDLE, Pull
7 144015 2 • • MOUNT, Anti-vibration
8 115649 2 • • NUT, Hex lock (1/4”-20 Grade 5, nylon)
9 103995 2 • • WASHER, Flat (1/4”)
10 157052 1 • • HASP, Padlock
11 167202 3 • • SCREW, Flat head machine (#10-32 x 0.75")
12 154323 1 • BRACKET, Gas spring
13 162101 1 • GAS SPRING, Control box cover
14 103891 2 • BOLT, Hex head (1/4”-20 x 7/8” Grade 5)
15 139168 8 • SCREW, Button head cap (1/4”-20 x 3/4”)
16 103995 16 • WASHER, Flat (1/4”)
17 115649 10 • NUT, Hex lock (1/4”-20 Grade 5, nylon)
18 103984 2 • NUT, Hex lock (5/16”-18 Grade 5, nylon)
19 159956 4 • WASHER, Rubber (1/4”)
20 162048 1 • PLATE, Right side cover
21 162050 1 • PLATE, Back cover
22 162049 1 • PLATE, Left side cover
23 159960 4 • SPACER, (3/4” OD)
24 103858 2 • BOLT, Hex head (1/4"-20 x 1 1/4" Grade 5)
25 103996 2 • WASHER, Flat (5/16")
26 162123 2 • STUD, Ball (10mm x 0.54")
27 105621 4 • SCREW, Round head machine (#10-32 x 1.00”)
28 300450 4 • NUT, Hex head nylon lock (#10-32, Grade 5)
29 104694 4 • WASHER, Flat (#10)
30 190020 4 • SPACER, Plastic (0.50” OD x 0.3125” long x 0.26” ID)
31 162078 1 • INSTRUCTION, Installation (not shown)
