Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 277
9.37 Tool Caddy
AE
Index
No.
Skyjack
Part No.
Qty. Description
- 211271 1 TOOL CADDY KIT
- 204334 1 • TOOL CADDY ASSEMBLY
1 198945 1 • • TOOL CADDY TRAY, Plastic (Std)
2 198965 2 • • PIN, Quick release 1/4x3.2 LG with Lanyard
3 116161 2 • • RIVET, Pop (0.1875” x 0.565”)
4 172293 2 • • LABEL, Skyjack logo, 5” white
5 172294 1 • • LABEL, Skyjack logo, 3” white
6 168421 3 • • LABEL, Lock pin in place
7 172245 1 • • LABEL, Tool caddy weight
8 172246 1 • • LABEL, Tool caddy pin location
9 172247 1 • • LABEL, Tool caddy location
10 172292 1 • • LABEL, Accessoryzers, 8” white
11 172298 1 • • LABEL, Tool caddy models serial numbers
12 172299 1 • • LABEL, Do not block exit/entrance
13 172297 1 • • LABEL, Drive slowly when tool caddy is installed
14 172428 1 • • LABEL, CE mark
15 204306 1 • INSTRUCTIONS, Tool caddy installation (not shown)
