Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 31
2.1 Main & Fly Boom Assembly
Index
No.
Skyjack
Part No.
Qty. Description
A 161976 1 MAIN AND FLY BOOM ASSEMBLY (SJ 46AJ)
B 162446 1 MAIN AND FLY BOOM ASSEMBLY (SJ 51AJ)
161977 1 • MAIN BOOM ASSEMBLY, A
162447 1 • MAIN BOOM ASSEMBLY, B
1 161981 1 • • MAIN BOOM WELDMENT, A
162451 1 • • MAIN BOOM WELDMENT, B
2 148843 1 • • PIN (1 3/4” diameter x 9 1/2”)
3 148844 1 • • PIN (1.25” diameter x 9”)
4 146898 1 • • KEEPER PIN (5/8”)
5 146897 1 • • KEEPER PIN (3/8”)
6 148826 1 • • PAD, Bottom
7 148827 1 • • PAD, Top
8 148828 4 • • PAD, Side
9 148829 AR • • SHIM, 16 Gauge (top)
148830 AR • • SHIM, 20 Gauge (top)
10 148837 AR • • SHIM, 16 Gauge (side)
148838 AR • • SHIM, 20 Gauge (side)
11 148817 2 • • BUSHING (2” ID x 2”)
12 148847 1 • • BUSHING (1 1/4” ID x 1”)
13 149267 2 • • SPACER (Extension cylinder)
14 300437 4 • • BOLT, Hex head (3/8”-16 x 7/8” Grade 5)
15 101297 12 • • BOLT, Hex head (3/8”-16 x 1 1/4” Grade 5)
16 149015 1 • • BOLT, Hex head/patch (5/8”-16 x 7/8” Grade 8, ZP)
17 139193 1 • • BOLT, Hex head patch (3/8”-16 x 7/8” Grade 8, ZP)
18 125959 19 • • WASHER, Flat (3/8”)
19 700782 1 • • WASHER, Flat (5/8”)
20 152306 1 • • PAD, Wear - boom
21 103871 2 • • BOLT, Hex head (3/8”-16 x 1.75” Grade 5)
22 (Ref.) 1 • FLY BOOM ASSEMBLY
(For components, refer to Section 2.3)
23 (Ref.) 1 • E-CHAIN ASSEMBLY
(For components, refer to Section 2.5)
- 161980 1 • BOOM EXTEND LIMIT SWITCH ASSEMBLY, A
-
162450 1 • BOOM EXTEND LIMIT SWITCH ASSEMBLY, B
24 112248 2 • • SCREW, Round head machine (#8-32 x 1”)
25 103991 2 • • WASHER, Flat (#8)
26 138765 2 • • NUT, Hex lock (#8-32 Grade 5, nylon)
27 160015 1 • • CORD, Switch (17m)
28 160018 1 • • SWITCH, Limit (with adjustable lever arm)
29 (Ref.) 1 • EXTENSION CYLINDER
(For components, refer to Section 3.1)
30 (Ref.) 1 • MAIN BOOM LIFT CYLINDER
(For components, refer to Section 3.2)
Parts list continued from the previous page.
