Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 39
2.4 Riser Boom Assembly
Index
No.
Skyjack
Part No.
Qty. Description
Parts list continued from the previous page.
26 103916 2 • • BOLT, Hex head (3/8”-16 x 3.25”, Grade 5)
27 104606 4 • • NUT, Hex head nylon lock (3/8”-16, Grade 5)
28 148855 2 • COVER, Riser
29 112495 10 • BOLT, Hex head (1/4”-20 x 3/8” Grade 5)
30 103995 10 • WASHER, Flat hardened (1/4”)
31 148819 6 • PIN (2” diameter x 11.063”)
32 146898 9 • KEEPER PIN (5/8”)
33 148944 9 • BOLT, Hex head patch (5/8”-11 x 1 3/4” Grade 8)
34 700782 9 • WASHER, Flat hardened (5/8”)
35 103472 6 • WASHER, Flat (3/8”)
