Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 41
2.5 E-Chain Assembly
Index
No.
Skyjack
Part No.
Qty. Description
A 161979 1 E-CHAIN ASSEMBLY (SJ46AJ)
B 162449 1 E-CHAIN ASSEMBLY (SJ51AJ)
1 161990 1 • TUBE, E-chain upper, A
162457 1 • TUBE, E-chain upper, B
2 161992 1 • TUBE, E-chain lower, A
162459 1 • TUBE, E-chain lower, B
3 161993 1 • CLAMP, Hose
4 710210 1 • PLATE, Hose guide
5 139168 8 • SCREW, Button head cap (1/4”-20 x 0.75”)
6 103472 11 • WASHER, Flat (3/8”)
7 103995 8 • WASHER, Flat (1/4”)
8 103996 4 • WASHER, Flat (5/16”)
9 144238 7 • NUT, Torque lock (3/8”-16 Grade C)
10 115649 4 • NUT, Hex head nyloln lock (1/4”-20 Grade 5)
11 103984 2 • NUT, Hex head nyloln lock (5/16”-18 Grade 5)
12 103867 2 • BOLT, Hex head (5/16”-18 x 3.00” Grade 5)
13 103473 4 • BOLT, Hex head (3/8”-16 x 1.00” Grade 5)
14 168334 1 • E-CHAIN, 250 series, 26 links, A
168335 1 • E-CHAIN, 250 series, 35 links, B
210078 1 • • MOUNTING BRACKET SET
210077 A/R • • LINK, E-Chain
210074 A/R • • SEPARATOR, E-Chain
15 103949 3 • SCREW, Button head cap (3/8”-16 x 1.00”)
16 196488 1 • PAD, Wear
AD
To Next Page
