Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 45
2.7 Jib Manifold
Index
No.
Skyjack
Part No.
Qty. Description
- 167646 - JIB MANIFOLD ASSEMBLY
- 162497 - • MANIFOLD ASSEMBLY, Jib/Platform rotate
1 166036 2 • • SV08-47D-0-N-00
2 159821 4 • • COIL 4304012
3 121250 2 • • PORT PLUG 6103004
4 166071 1 • • BLOCK
5 167649 1 • COVER, Valve
6 129127 4 • FITTING, Elbow, 90° (04 JICM - 06 ORBM)
7 701956 2 • FITTING, Straight (04 JICM - 06 ORBM)
8 104437 1 • FITTING, Plug (06 ORBM)
9 103856 3 • BOLT, Hex head (0.25”-20 x 0.75” Grade 5)
10 120738 2 • BOLT, Hex head (0.25”-20 x 4.00” Grade 5)
11 103995 5 • WASHER, Flat (1/4”)
12 104000 5 • WASHER, Lock (1/4”)
