Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 49
3.1 Extension Cylinder
Index
No.
Skyjack
Part No.
Qty. Description
A 148700 - EXTENSION CYLINDER (SJ 46AJ)
B 148699 - EXTENSION CYLINDER (SJ 51AJ)
- 148712 - • EXTENSION CYLINDER, A
- 148713 - • EXTENSION CYLINDER, B
1 154547 1 • • WELDMENT, Tube, A
154538 1 • • WELDMENT, Tube, B
2 154539 1 • • NUT, Rod
3 154543 1 • • PISTON
4 154546 1 • • STOP SLEEVE
5 154544 1 • • GLAND
6 154548 1 • • WELDMENT, Rod, A
154540 1 • • WELDMENT, Rod, B
7 141453 1 • • VALVE, Counterbalance (1000 psi)
8 149228 1 • • VALVE, Counterbalance (3000 psi)
9 128869 1 • FITTING, Straight (06 JICM - 06 ORBM)
10 702761 1 • FITTING, Elbow 90° (06 JICM - 06 JICFSW)
11 113348 1 • FITTING, Elbow 90° (06 JICM - 06 ORBM)
12 152417 2 • PAD, Wear
13 103596 4 • BOLT, Hex head (3/8”-16 x 2” Grade 5)
14 103472 8 • WASHER, Flat (3/8”)
15 104606 4 • NUT, Hex lock (3/8”-16 Grade 5, nylon)
K1 154537 1 KIT, Seal, A
154655 1 KIT, Seal, B
