Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 63
4.2 Cowling Assembly - Engine Side
Index
No.
Skyjack
Part No.
Qty. Description
- 148615 1 COWLING ASSEMBLY, ENGINE SIDE
- 149259 1 • COWLING, Assembly (Engine Side)
1 149261 1 • • COWLING, Shell (Engine Side)
2 160214 1 • • WELDMENT, Cowling frame (Engine Side)
3 152426 2 • • PLATE, Perforated
4 148368 1 • • FOAM, 2” x 2” (#1441FR)
5 125959 4 • • WASHER, Flat hardened (3/8”)
6 127067 4 • • WASHER, Flat (3/8” Style BB)
7 101297 2 • • BOLT, Hex head (3/8”-16 x 1 1/4” Grade 5)
8 104606 4 • • NUT, Hex lock (3/8”-16 Grade 5, nylon)
9 103870 2 • • BOLT, Hex head (3/8”-16 x 1 1/2” Grade 5)
10 152416 2 • • WASHER, Rubber (1x 3/7 x 1/8 TK)
11 149360 1 • WELDMENT, Gas spring mount
12 152427 2 • WELDMENT, Hinge lower RHS
13 103980 2 • NUT, Hex head (1/4”-20 Grade 8)
14 138834 4 • SCREW, Round machine (#10-24 x 3/4”)
15 104694 2 • WASHER, Flat (#10)
16 126642 4 • NUT, Hex lock (#10-24 Grade 5, nylon)
17 146903 2 • STUD, Ball (10mm)
18 103984 2 • NUT, Hex lock (5/16”-18 Grade 5, nylon)
19 125959 10 • WASHER, Flat hardened (3/8”)
20 103473 10 • BOLT, Hex head (3/8”-16 x 1” Grade 5)
21 152431 1 • GAS SPRING, Cowling
22 138736 2 • BOLT, Hex head (3/8”-16 x 6” Grade 5)
23 104606 2 • NUT, Hex lock (3/8”-16 Grade 5, nylon)
24 149333 1 • WELDMENT, Latch mount
25 149334 1 • WELDMENT, Cowling bumper
26 103995 3 • WASHER, Flat (1/4”)
27 103857 3 • BOLT, Hex head (1/4”-20 x 1” Grade 5)
28 144002 1 • LATCH, Flexible draw
29 144015 2 • MOUNT, Anti-vibration
