Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 69
4.5 Engine Tray Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 162286 1 ENGINE TRAY ASSEMBLY
1 162312 1 • ENGINE TRAY WELDMENT
3 146903 2 • STUD, Ball (10mm)
3 146902 1 • GAS SPRING
4 162319 2 • PIN, Pivot (1.25” OD x 2.875”)
5 162321 2 • PLATE, Pin lock (1.25” OD x 0.188”)
6 121703 1 • WASHER, Thrust - fiberglide
7 103472 2 • WASHER, Flat (3/8”)
8 103468 1 • WASHER, Flat (0.50” SAE AA)
9 103996 1 • WASHER, Flat (5/16”)
10 103897 1 • BOLT, Hex head (5/8”-16 x 2.00” Grade 5)
11 103984 1 • NUT, Hex head nylon lock (5/16”-18 Grade 5)
12 103473 2 • BOLT, Hex head (3/8”-16 x 1.00” Grade 5)
13 103981 1 • NUT, Hex head (5/8”-11 Grade 5)
14 100071 2 • BUSHING, Fiberglide
15 103907 1 • BOLT, Hex head (0.50”-13 x 1.50” Grade 5)
16 169579 1 • BRACKET, Cowling mount
17 125959 4 • WASHER, Flat hardened (3/8”)
18 103870 2 • BOLT, Hex head (3/8”-16 x 1.50” Grade 5)
19 104606 2 • NUT, Hex head (3/8”-16 Grade 5)

Skyjack SJ51AJ Specifications

General

Brand	Skyjack
Model	SJ51AJ
Category	Boom Lifts
Language	English
