Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 71
4.6 Manifold Assembly with Hardware
Index
No.
Skyjack
Part No.
Qty. Description
- 167490 - MANIFOLD ASSEMBLY WITH HARDWARE (ANSI/CSA)
- 167570 - MANIFOLD ASSEMBLY WITH HARDWARE (CE & AS)
1 (Ref.) 1 • MAIN MANIFOLD
(For components, refer to Section 4.7)
2 (Ref.) 1 • BRAKE MANIFOLD
(For components, refer to Section 4.8)
3 163182 1 • VALVE ASSEMBLY, Check
166075 1 • • BLOCK, Check Valve
159815 1 • • VALVE, Check
4 163183 1 • VALVE ASSEMBLY, Check
166075 1 • • BLOCK, Check Valve
166066 1 • • VALVE, Check
5 163710 1 • FITTING, Orifice
6 114581 2 • FITTING, Tee (06 JICM - 06 ORBM - 06 JICM)
7 103069 1 • FITTING, Straight (06 JICM - 06 ORBM)
8 702761 1 • FITTING, Elbow 90° swivel (06 JICM - 06 JICF)
9 125959 2 • WASHER, Flat hardened (3/8”)
10 138736 2 • BOLT, Hex head (0.375”-16 x 6.00 gr 5)
11 103995 2 • WASHER, Flat (1/4”)
12 103859 2 • BOLT, Hex head (1/4”-20 x 1.50” Grade 5)
13 103996 8 • WASHER, Flat (5/16”)
14 100397 3 • NUT, Hex head (5/16”-18, Grade 5)
15 138762 3 • BOLT, Hex head (5/16”-18 x 5.00”, Grade 5)
16 103984 2 • NUT, Hex head nylon lock (5/16”-18, Grade 5)
17 103864 2 • BOLT, Hex head (5/16”-18 x 1.00”, Grade 5)
18 (Ref.) 1 • PRESSURE REDUCING MANIFOLD
(For components, refer to Section 4.10)
