Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 73
4.7 Main Manifold
AD
Index
No.
Skyjack
Part No.
Qty. Description
A 167494 - MAIN MANIFOLD ASSEMBLY (ANSI/CSA)
B 167897 - MAIN MANIFOLD ASSEMBLY (CE & AS)
- 162495 1 • MANIFOLD ASSEMBLY, Main
1 166070 1 • • BLOCK, Manifold
2 166067 6 • • VALVE, Check
3 166080 1 • • ORIFICE, Plug (0.038”)
4 166078 1 • • ORIFICE, Plug (0.058”)
5 166064 1 • • VALVE, Check
6 159817 1 • • VALVE, Check (Pilot operated)
7 166063 2 • • COMPENSATOR, Pressure
8 166062 2 • • COMPENSATOR, Pressure
9 166059 1 • • COMPENSATOR, Pressure
10 166055 1 • • REGULATOR, Pressure
11 166057 1 • • REGULATOR, Pressure
12 166056 1 • • REGULATOR, Pressure
13 159821 6 • • COIL, 12 VDC
14 159819 9 • • COIL, 12 VDC
15 166054 5 • • VALVE, Shuttle
16 168975 1 • • VALVE, Relief
17 159809 1 • • VALVE, Relief
18 166044 1 • • VAVLE, Differential relief
19 166043 1 • • VAVLE, Differential relief
20 166041 3 • • VALVE, Spool (3 position 4 way)
21 166038 2 • • VALVE, Spool (2 way)
22 166037 2 • • VALVE, Spool (3 way)
23 158186 1 • • VALVE, Spool (3 position 4 way)
24 166036 1 • • VALVE, Spool (3 position 4 way)
25 166039 1 • • VALVE, Spool (2 way)
27 121250 3 • PLUG, Hex socket (04 ORBM)
28 706812 1 • FITTING, Straight (08 JICF - 04 JICM)
29 128869 4 • FITTING, Straight (06 JICM - 06 ORBM), A
128869 3
• FITTING, Straight (06 JICM - 06 ORBM), B
30 701478 1 • FITTING, Elbow 45° (06 JICM - 04 ORBM)
31 131716 1 • FITTING, Elbow 45° (04 JICM - 04 ORBM)
32 126128 10 • FITTING, Straight (04 JICM - 04 ORBM)
33 111392 1 • PLUG, Hex socket (12 ORBM)
34 131705 1 • FITTING, Straight (08 ORBM - 04 JICM)
35 103070 1 • FITTING, Straight (06 JICM - 08 ORBM)
702796 1 • PLUG, Hex socket (08 ORBM)
36 702118 1 • FITTING, Straight (12 JICM - 12 ORBM)
37 135061 1 • FITTING, Tee (08 JICM - 08 JICM - 08 ORBM)
38 107666 2 • FITTING, Cap (06 JICF), A
1 • FITTING, Cap (06 JICF), B
39 147553 1 • FITTING, Straight (04 ORBM - 06 ORBF), B
40 122420 1 • QUICK DISCONNECT ASSEMBLY, B
41 702761 1 FITTING, Elbow 90° (06 JICM - 06 JICFSW)
