Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 79
4.10 Pressure Reducing Manfold
Index
No.
Skyjack
Part No.
Qty. Description
- 168993 1 PRESSURE REDUCING VALVE (serial number 95 001 716 and below)
1 168536 1 • BRACKET
- 168994 1 • PRESSURE REDUCING MANIFOLD ASSEMBLY
- 168158 1 • • MANIFOLD, Pressure Reducing
2 138241 1 • • • BLOCK, Manifold
3 168242 1 • • • VALVE, Relief
4 168243 1 • • • VALVE, Check
5 129127 3 • • FITTING, Elbow 90° (04 JICM - 06 ORBM)
6 144628 1 • • FITTING, Hex head plug (04 NPTM brass)
7 103865 2 • BOLT, Hex head (5/16”-18 x 2.00” Grade 5)
8 103984 2 • WASHER, Flat (5/16”)
9 103996 2 • NUT, Hex head nylon lock (5/16”-18, Grade 5)
