Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 81
4.11 Rotary Manifold Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 167709 - ROTARY MANIFOLD ASSEMBLY - serial number 95 002 084 & below
1 149380 1 • MANIFOLD, Rotary
2 149378 2 • BRACKET, Rotary manifold
3 138956 1 • SPACER, Rotary manifold
4 104379 1 • WASHER, Flat hardened (1/2”)
5 103904 1 • BOLT, Hex head (1/2”-13 x 2” Grade 5)
6 103472 4 • WASHER, Flat (3/8”)
7 101632 4 • BOLT, Hex head (3/8”-16 x 3/4” Grade 5)
8 125883 7 • FITTING, Elbow, 90° (04 JICM - 04 ORBM)
9 131716 4 • FITTING, Elbow, 45° (04 JICM - 04 ORBM)
10 114583 1 • FITTING, Elbow, 90° (08 JICM - 08 ORBM)
11 126128 3 • FITTING, Straight (04 JICM - 04 ORBM)
12 102659 1 • FITTING, Straight (08 JICM - 08 ORBM)
13 139099 1 • FITTING, Elbow, 90° LL (12 JICM - 12 ORBM)
14 105445 2 • FITTING, Elbow, 90° (12 JICM - 12 ORBM)
15 131707 1 • FITTING, Elbow, 45° (12 JICM - 12 ORBM)
K 154659 1 KIT, Seal (Rotary Manifold)
- 148610 - DIRECTION SENSING LIMIT SWITCH - serial number 95 002 084 & below
16 122007 1 • SWITCH, Limit
17 126499 2 • SCREW, Machine round head (#8-32 x 0.88”)
