Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 85
4.14 Fuel Tank Assembly - Deutz D2011 Engine
Index
No.
Skyjack
Part No.
Qty. Description
- 148660 - FUEL TANK ASSEMBLY - Deutz D2011 engine
- 164830 1 • TANK ASSEMBLY, Diesel
1 138230 1 • • SWITCH, Fuel level
2 137629 1 • • FITTING, Plug hollow hex (10 ORB)
3 103155 1 • • FITTING, Brass tank (#T68-5B)
4 144410 1 • • CAP, Fuel (non EPA)
5 138491 1 • • TUBE, Fuel send/return
6 143478 1 • • FITTING, Nipple (brass, 1/4 NPT x 2”)
7 144325 1 • • FITTING, Elbow 90° (brass, 1/4 NPTF x 1/4 NPTF)
8 116408 1 • • VENT, Breather (1/4 NPT)
9 164829 1 • • TANK, Fuel
10 164674 1 • • FITTING, Tube Compression (1/2” OD x 1/2” NPT)
11 164673 1 • • TUBE, Fuel suction
12 125959 4 • WASHER, Flat (3/8”)
13 101632 2 • BOLT, Hex head (3/8”-16 x 3/4” Grade 5)
14 103872 2 • BOLT, Hex head (3/8”-16 x 2 1/4” Grade 5)
15 103999 4 • WASHER, Lock (3/8”)
16 165716 1 • FITTING, Straight (08 BT - 06 FP)
17 165719 1 • FITTING, Hose barb
18 (Ref.) - FUEL
(For components, refer to Section 11.1)
