Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 87
4.15 Fuel Tank Assembly - GM & Kubota Dual Fuel Engines
Index
No.
Skyjack
Part No.
Qty. Description
- 148676 1 FUEL TANK ASSEMBLY - GM & Kubota WG2503 engine
- 149069 1 • FUEL TANK ASSEMBLY (Gasoline, steel)
1 149070 1 • • TANK, Fuel (steel)
2 103155 2 • • FITTING, Brass tank (#T68-5B)
3 144338 2 • • TUBE, Fuel send/return
4 138230 1 • • SWITCH, Fuel level
5 117701 1 • • PLUG (3/4”-16UNF with magnet)
6 144393 1 • • GAUGE, Level
7 136369 1 • • CAP, Fuel (filler non-vented)
8 144392 1 • • VALVE, Dual action
9 125959 4 • WASHER, Flat (3/8”)
10 103999 4 • WASHER, Lock (3/8”)
11 103596 2 • BOLT, Hex head (3/8”-16 x 2” Grade 5)
12 101632 2 • BOLT, Hex head (3/8”-16 x 3/4” Grade 5)
13 142397 2 FITTING, Quick disconnect (straight)
14 (Ref.) - FUEL
(For components, refer to Section 11.1)
AB
