Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 89
4.16 Hydraulic Tank Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 162287 - HYDRAULIC TANK WITH FITTINGS ASSEMBLY
- 162322 - • HYDRAULIC TANK ASSEMBLY
1 162323 1 • • TANK WELDMENT, Hydraulic
2 152393 1 • • GASKET, Hydraulic tank
3 152392 1 • • COVER, Hydraulic tank
4 103236 1 • • INDICATOR, Level
5 103472 4 • • WASHER, Flat hardened (3/8”)
6 300437 4 • • BOLT, Hex head (3/8”-16 x 0.875” Grade 5)
7 161934 1 • FILTER ASSEMBLY, Return
161949 1 • • ELEMENT, Return filter
168869 1 • • ELEMENT, Breather
168870 1 • • LID, Return filter
168871 1 • • CAP, Air element
8 126361 1 • BOLT, Hex head (1/2”-13 x 1.75” Grade 8)
9 103910 1 • BOLT, Hex head (1/2”-13 x 1.25” Grade 8)
10 103468 2 • WASHER, Flat (1/2” SAE AA)
11 103472 4 • WASHER, Flat (3/8”)
12 103870 2 • BOLT, Hex head (3/8”-16 x 1 1/2” Grade 5)
13 103596 2 • BOLT, Hex head (3/8”-16 x 2” Grade 5)
14 702122 1 • FITTING, Straight (12 JICM - 16 ORBM)
15 138667 2 • FITTING, Straight (16 JICM - 16 ORBM)
16 114583 2 • FITTING, Elbow 90° (08 JICM - 08 ORBM)
17 131705 1 • FITTING, Straight (04 JICM - 08 ORBM)
18 139207 1 • FITTING, Elbow 90° long (12 JICM - 12 ORBM)
19 143980 1 • FITTING, Plug - magnetic (08 ORBM)
20 707917 1 • FITTING, Run Tee (04 JICM - 04 JICM - 04 JICFS)
