Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 93
4.19 Battery Assembly
Index
No.
Skyjack
Part No.
Qty. Description
- 167488 1 BATTERY ASSEMBLY
1 157464 1 • PAD, Battery
2 144676 1 • BATTERY (12V, 950 CCA)
3 150959 1 • BRACKET, Battery retainer
4 150960 1 • HOLD DOWN, Battery (pair)
5 119725 1 • SWITCH, Main lockout
6 108714 1 • MOUNT, Lock out switch
7 159915 1 • CABLE, Weld (#2/0 3/8” x 22 x 3/8”)
8 138700 1 • CABLE, Battery
139030 1 • • CLAMP, Battery post - positive
139032 1 • • BOOT, Battery post - red
139105 1 • • BOOT, Terminal - red
9 103472 6 • WASHER, Flat (3/8”)
10 154243 1 • CABLE, Weld (#2/0, 21” x 3/8”)
139031 1 • • CLAMP, Battery post - negative
11 144129 1 • CLIP, Single (S332G10)
12 152341 1 • BOLT, Hex head (0.375”-16 x 0.50” Grade 5)
13 138704 1 • CABLE, Battery
139106 1 • • BOOT, Terminal - red
14 103995 2 • WASHER, Flat (0.25”)
15 115649 2 • NUT, Lock (0.25”-20 gr 5)
L 119674 1 • LABEL, Battery Disconnect
- 170482 1 CHARGE INDICATOR ASSEMBLY
16 152323 1 • INDICATOR, Charge
17 152344 1 • WIRE ASSEMBLY, Charge indicator (00) (not shown)
18 152345 1 • WIRE ASSEMBLY, Charge indicator (03) (not shown)
