Skyjack SJ51AJ Parts Manual

Articulating Boom Series
Models SJ46AJ & SJ51AJ
170947
SKYJACK, Page 95
4.20 Base Control Box - Deutz D2.9L
Index
No.
Skyjack
Part No.
Qty. Description
- 165541 - BASE CONTROL ASSEMBLY (46AJ ANSI/CSA - Deutz D2.9L)
- 164929 1 • BASE CONTROL CONSOLE ASSEMBLY, Deutz
- 164931 1 • • CONTROL BOX
1 164932 1 • • • BODY, Control box
149281 1 • • • HINGE, Continuous
2 164933 1 • • • DOOR, Control box
3 149282 1 • • • WEATHER STRIP
4 149437 1 • • • FASTENER, Door
149320 1 • • • RETAINER, 1/4 Turn
149321 1 • • • RECEPTACLE, 1/4 Turn
5 103336 1 • • HOUR METER
6 102853 6 • • SWITCH, Toggle
7 138278 3 • • SWITCH, Toggle
8 149426 1 • • ANGLE TRANSDUCER
9 164949 1 • • KEYSWITCH ASSEMBLY
147056 1 • • • LATCH, Mounting
166141 1 • • • BLOCK, NOEM Contact (black plunger)
166142 1 • • • BLOCK, NCLB Contact (yellow plunger)
149605 1 • • • SWITCH HEAD, Selector
10 144652 1 • • SWITCH, Emergency stop red
147056 1 • • • LATCH, Mounting
147053 1 • • • BLOCK, NC Contact
147229 1 • • • BLOCK, LED 12V
147051 1 • • • SWITCH HEAD, Emergency stop
11 164831 1 • • LIGHT INDICATOR, Green
12 133133 2 • • LIGHT INDICATOR, Amber
13 117325 3 • • CIRCUIT BREAKER (15 AMP)
14 116266 5 • • CONNECTOR, Heyco liquid tight
15 131938 1 • • PLUG (1 1/8”)
16 138749 14 • • SOCKET, Automotive relay
17 127131 11 • • RELAY, (12V 40 AMP)
18 164816 1 • • TERMINAL STRIP
(For components, refer to Section 4.22)
19 138751 3 • • HOUSING, Open bottom 24 pin levered
20 138755 1 • • PLUG, 24 Pin spring (16A)
21
138756 2 • • SOCKET, 24 Pin spring (16A)
22 126499 2 • • SCREW, Round head machine (#8-32 x 7/8”)
23 138765 16 • • NUT, Hex lock (#8-32 Grade 5, nylon)
24 104694 6 • • WASHER, Flat (#10)
25 104003 6 • • NUT, Hex head (#10-32)
26 103957 14 • • SCREW, Round head machine (#8-32 x 1/2”)
27 103056 1 • • BEEPER (7.5 - 16 VDC)
Parts list continued from the previous page.
