Skyjack SJKB-40-D - Page 108

SECTION 5, Page 25SJKB-40-D, SJKB-40-D/F
JUN. 1999
11
10
9
7
6
53
2
1
Figure 5-15 Drive Pump Test Ports
Figure 5-16 Rotary Manifold
REVERSE PRESSURE
GAUGE PORT
RV3 CHARGE
PRESSURE RELIEF
VALVE
FORWARD
PRESSURE GAUGE
PORT
CAP
REVERSE DRIVE
HOSE
DRIVE MOTOR
CASE DRAIN
FORWARD
DRIVE HOSE
FRONT
Ma40-512
Ma40-513
