Skyjack SJKB-40-D - FIGURE 6-44. TRANSFER CASE ASSEMBLY (Optional 4 X4)

SECTION 6, Page 85
SJKB-40-D,SJKB-40-D/F
JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-44. TRANSFER CASE ASSEMBLY (Optional 4x4)
Ma40-82
1 706540 SEAL, O-ring 1
2 706541 SEAL, Oil 1
3 701843 WASHER, Oil seal 2
4 706542 SEAL, Oil 1
5 706543 SEAL, O-ring 1
5
4
3
2
1
3
