Skyjack SJKB-40-D - FIGURE 6-40. PLANETARY REDUCTION GEAR ASSEMBLY (Sige)

SECTION 6, Page 79
SJKB-40-D,SJKB-40-D/F
JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-40. PLANETARY REDUCTION GEAR ASSEMBLY (Sige)
Ma40-631
1 701960 LIP SEAL, Output housing 1
2 $ HOUSING, Output 1
3 701961 O-RING SEAL 3
4 $ RING GEAR 1
5 $ HOUSING, Input 1
6 701962 LIP SEAL, Input adapter 1
7 $ HOUSING, Input adapter 1
$ Consult factory
