Skyjack SJKB-40-D - FIGURE 6-30. ENGINE and RELATED PARTS (Diesel)(Option)

SJKB-40-D, SJKB-40-D/F SECTION 6, Page 65
JUN. 1999
103473 • BOLT, HHCS 3/8-16 x 1” lg. Grade 5 2
103999 • WASHER, Lock 3/8” 2
103472 • WASHER, Flat 3/8” 2
702119 • FITTING, Elbow 90° swivel #12 - #12 1
704582 • FITTING, Connector #10orb - #12 1
703533 • FITTING, Elbow 90° #10orb - #8 1
19 707241 PLATE, Engine baffle 1
20 706984 MOUNTING BRACKET, Oil cooler 2
21 702031 COOLER, Oil 1
103984 • NUT, Lock 5/16-18 2
701879 • FITTING, Connector #16 - #12 2
22 708591 MOUNTING BRACKET, Overflow reservoir 1
$ • BOTTLE, Overflow 1
710196 • CLAMP, Hose 1
708493 • ZIP TIE 2
23 708243 PLATE, Radiator guard 1
701054 • BOLT, HHCS 8M-1.25 x 40MM lg. 1
701056 • WASHER, Lock 8M 1
701055 • NUT, Hex 8M-1.25 1
24 706661 BRACKET, Oil filter 1
103473 • BOLT, HHCS 3/8-16 x 1” lg. grade 5 2
103472 • WASHER, Flat 3/8” 2
104606 • NUT, Lock 3/8-16 2
25 706814 FILTER, Medium pressure oil 1
708333 • ELEMENT, Oil filter 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. grade 5 4
103999 • WASHER, Lock 3/8” 4
109052 • FITTING, Connector #12orb - #6 2
702761 • FITTING, Swivel nut elbow 90° #6 - #6 1
26 704746 WELDMENT, Engine mounting bracket 1
707637 • BOLT, HHCS 10MM-1.25 x 30MM lg. 2
103908 • BOLT, HHCS 1/2-20 x 1-1/2 lg. grade 5 2
103468 • WASHER, Flat 1/2” SAE 2
103470 • WASHER, Lock 1/2” 2
27 704747 WELDMENT, Engine mounting bracket 1
707637 • BOLT, HHCS 10MM-1.25 x 30MM lg. 2
103908 • BOLT, HHCS 1/2-20 x 1-1/2 lg. grade 5 2
103468 • WASHER, Flat 1/2” SAE 2
103470 • WASHER, Lock 1/2” 2
28 105807 LANYARD, 6” 1
29 707775 SPLIT RING, 1” 1
30 706448 WELDMENT, Latch bolt 1
31 702672 MOUNT, Motor 4
103857 • BOLT, HHCS 1/4-20 x 1” lg. grade 5 8
103995 • WASHER, Flat 1/4” SAE 8
700583 • NUT, Lock 1/4-20 8
32 706290 WELDMENT, Engine tray 1
707029 • WASHER, Thrust 1
707046 • RETAINING RING, 2.25 Dia. 1
33 707698 PLATE, Door rest 1
702195 • BOLT, HHCS 3/8-16 x 1-1/2” lg. grade 5 2
103472 • WASHER, Flat 3/8” 2
103999 • WASHER, Lock 3/8” 2
702929 • NUT, Hex jam 3/8-16 2
FIGURE 6-30. ENGINE AND RELATED PARTS (Diesel) (Option)
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
1 706185 ENGINE ASSEMBLY, Kubota 1
711459 • FILTER, Oil 1
711458 • FILTER, Fuel 1
119184 • ASSEMBLY, Glow plug 1
708250 • ASSEMBLY, Fuel line 1
2 708334 ASSEMBLY,Air cleaner 1
708335 • ELEMENT, Air filter 1
702557 • CLAMP, #40 Gear 2
3 708337 HOSE, Air cleaner intake 1
702557 • CLAMP, #40 Gear 2
4 704949 VALVE, Shuttle cartridge 1
701850 • FITTING, Elbow 90° #4orb - #4 2
701954 • FITTING, Connector #4orb - #4 1
5 706660 BRACKET, Terminal strip/Relay 1
103860 • BOLT, HHCS 1/4-20 x 1-3/4 lg. grade 5 1
103995 • WASHER, Flat 1/4” SAE 1
700583 • NUT, Lock 1/4-20 1
6 701943 RELAY, 12VDC Sealed 4
7 103011 TERMINAL STRIP, Large 1
8 704665 COVER, Terminal strip/Relay 1
9 707651 WELDMENT, Exhaust pipe mounting bracket 1
10 707264 EXHAUST PIPE 1
707758 • EXHAUST CLAMP, U-Shaped 1-1/2” 1
707747 • EXHAUST CLAMP, U-Shaped 1-1/4”
11 706961 BRACKET, Throttle Solenoid 1
12 707675 THROTTLE SOLENOID 1
103857 • BOLT, HHCS 1/4-20 x 1” lg. grade 5 4
103995 • WASHER, Flat 1/4” SAE 4
104000 • WASHER, Lock 1/4” 4
103980 • NUT, Hex 1/4-20 4
13 707757 CLEVIS 1
103857 • BOLT, HHCS 1/4-20 x 1” lg. grade 5 1
700583 • NUT, Lock 1/4-20 1
14 707679 ROD END, Spherical 1
15 707782 LINK ARM 1
703460 • NUT, Hex jam 1/4 fine 3
16 703463 ROD END, Studded spherical 1
17 703693 PUMP, Hydraulic drive 1
103907 • BOLT, HHCS 1/2-13 x 1-1/2” lg. grade 5 2
103468 • WASHER, Flat 1/2” SAE 2
103470 • WASHER, Lock 1/2” 2
704582 • FITTING, Connector #10orb - #12 1
702119 • FITTING, Elbow 90° swivel #12 - #12 2
707036 • FITTING, Split flange #12 - #12 2
702233 • KIT, Split flange seal 2
701956 • FITTING, Connector #6orb - #4 1
103070 • FITTING, Connector #8orb - #6 1
701850 • FITTING, Elbow 90° #4orb - #4 1
703255 • FITTING, Extra long elbow 90° #8orb - #6 1
707039 • FITTING, Extra long elbow 90° #4orb - #4 1
707041 • FITTING, Reducer #4 - #6 1
704492 • FITTING, Elbow 90° #10orb - #6 1
707040 • FITTING, Elbow 90° #16orb - #16 1
18 704957 PUMP, Hydraulic system 1
MARCH, 2000
