Skyjack SJKB-40-D - Standard Hose Numbering System

SECTION 5, Page 30 SJKB-40-D, SJKB-40-D/F
JUN. 1999
H1104 0081 2-0
FITTING
ARRANGEMENT
(See Schedule
Below)
HOSE SIZE
(See Chart
Below)
LENGTH OF HOSE
IN WHOLE INCHES
LENGTH IN
FRACTIONS (1/4”
INCREMENTS)
I.E. 1=1/4”
2=1/2”
3=3/4”
REVISION LEVEL
HOSE SIZE CHART
FITTING ARRANGEMENT SCHEDULE
Using the number above as an example (H1104 0081 2 0). This hose requires a 37° JIC, female swivel fitting on one
end. A medium length 90° JIC, female swivel fitting for the other end. The Hose must meet or exceed S.A.E. 100R13
hose specification, and be a total of 81-1/2” long. NOTE: Hose ends and hose must be from same manufacturer per
S.A.E. J1273 Nov. ‘91, Sections 3.10 and 4.2. Hose ends and hose must be of the same size i.e. #4 size fittings must
be used with #4 size hose.
STANDARD HOSE NUMBERING SYSTEM
SIZE
03 04 06 08 10 12 16 20 24 32 40 48 56 64
I.D.
3/16" 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1-1/4" 1-1/2" 2" 2-1/2" 3" 3-1/2" 4"
HOSE PREFIX HOSE END FITTING HOSE END FITTING
S.A.E. HOSE
SPECIFICATION
H1 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R1
H2 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R13
H3 FEMALE, 37° JIC, SWIVEL 45°, FEMALE, 37° JIC, SWIVEL 100R1
H4 FEMALE, 37° JIC, SWIVEL 45°, FEMALE, 37° JIC, SWIVEL 100R13
H5 FEMALE, 37° JIC, SWIVEL LONG 90°, FEMALE, 37° JIC, SWIVEL 100R1
H6 FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R1
H7 LONG 90°, FEMALE, 37° JIC, SWIVEL LONG 90°, FEMALE, 37° JIC, SWIVEL 100R1
H8 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
H9 FEMALE, 37° JIC, SWIVEL 45°, FEMALE, 37° JIC, SWIVEL 100R4
H10 FEMALE, 37° JIC, SWIVEL MALE PIPE THREAD FITTING 100R1
H11 FEMALE, 37° JIC, SWIVEL MEDIUM 90°, FEMALE, 37° JIC, SWIVEL 100R13
H12 SHORT 90°, FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R1
H13 FEMALE, 37° JIC, SWIVEL REUSABLE MALE PIPE THREAD FITTING 300 PSI
H14 REUSABLE MALE PIPE THREAD FITTING NO FITTING 300 PSI
H15 REUSABLE, FEMALE, 37° JIC, SWIVEL REUSABLE, FEMALE, 37° JIC, SWIVEL 300 PSI
H16 NO FITTING NO FITTING 100R4
H17 NO FITTING NO FITTING 300 PSI
H18 REUSABLE, FEMALE, 37° JIC, SWIVEL NO FITTING 300 PSI
H19 LONG 90°, FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R13
H20 FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R4
H21 FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R2AT
H22 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R2AT
H23 FEMALE, 37° JIC, SWIVEL LONG 90°, FEMALE, 37° JIC, SWIVEL 100R2AT
H24 FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R13
H25 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
