SECTION 6, Page 13SJKB-40-D, SJKB-40-D/F
JUN. 1999
1 706017 ACTUATOR ASSEMBLY, Rotary (For components refer to Figure 6-10.) 1
2 700386 PIN, Jib Actuator 2
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 1
103404 • WASHER, Lock 5/16 1
3 707178 PARALLEL ASSEMBLY, Jib upper 1
100309 • BUSHING, 1” x 1-1/8” x 1” lg. 6
4 707179 PARALLEL ASSEMBLY, Jib lower 1
100309 • BUSHING, 1” x 1-1/8” x 1” lg. 6
102972 • HOSE CLAMP, G8 Double 2
103995 • WASHER, Flat SAE 1/4 2
103632 • SCREW, Self tapping 1/4-14 x 3/4” lg. 2
5 706003
CYLINDER/MANIFOLD ASSEMBLY, Jib lift (For components refer to Figure 6-6.) 1
6 700384 PIN, Jib parallel top 2
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 1
103404 • WASHER, Lock 5/16 1
7 704983 MAIN BOOM ASSEMBLY (For components refer to Figure 6-12.) 1
701805 RUBBER WEAR STRIP (Not shown) 7
8 700362 PIN, Lift Cylinder top 1
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 1
103404 • WASHER, Lock 5/16 1
9 700333 CYLINDER ASSEMBLY, Master (For components refer to Figure 6-7.) 1
10 700966 KNUCKLE ASSEMBLY 1
100904 • BUSHING, 1-1/2” x 1-5/8” x 1” lg. 2
100309 • BUSHING, 1” x 1-1/8” x 1” lg. 4
103216 • BUSHING, 1-1/2” x 1-5/8” x 1-1/2” lg. 2
11 700364 PIN, Upper knuckle 1
103915 • BOLT, HHCS 3/8-16 x 3-1/2” lg. 1
104606 • NUT, Lock 3/8-16 1
706872 • BOLT, HHCS 1/2-13 x 1-1/4” lg. 2
700425 • WASHER, Stop 2-1/4 DIA x 3/16” 2
12 700366 PIN, Master cylinder top 1
103873 • BOLT, HHCS 3/8-16 x 2-1/2” lg. 1
104606 • NUT, Lock 3/8-16 1
13 700430 PIN, Master cylinder bottom 1
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 1
103404 • WASHER, Lock 5/16 1
14 706000 CYLINDER ASSEMBLY, Lift (For components refer to Figure 6-8.) 1
15 711316 PIN, Lift cylinder bottom 1
706872 • BOLT, HHCS 1/2-13 x 1-1/4” lg. 1
700425 • WASHER, Stop 2-1/4 DIA x 3/16” 1
16 709448 PIN, Upper parallel 2
700425 • WASHER, Stop 2-1/4 DIA x 3/16” 2
709446 • SPACER, Pin 1
700342 WASHER, Bronze 2-1/2D. x 1-1/2I.D. (Not shown) 2
706872 • BOLT, HHCS 1/2-13 x 1-1/4” lg. 2
17 701102 PARALLEL UPPER ASSEMBLY, Riser 1
100904 • BUSHING, 1-1/2” x 1-5/8” x 1” lg. 2
103216 • BUSHING, 1-1/2” x 1-5/8” x 1-1/2” lg. 2
18 700964 PARALLEL LOWER ASSEMBLY, Riser 1
100904 • BUSHING, 1-1/2” x 1-5/8” x 1” lg. 2
103216 • BUSHING, 1-1/2” x 1-5/8” x 1-1/2” lg. 2
19 700994 HOSE COVER, Riser 1
20 700327 HOSE STRAP, Riser 1
21 704999 CYLINDER ASSEMBLY, Riser (For components refer to Figure 6-9.) 1
22 700347 PIN, Riser cylinder upper 1
103915 • BOLT, HHCS 3/8-16 x 3-1/2” lg. 1
104606 • NUT, Lock 3/8-16 1
23 704910 PIN, Riser cylinder lower 1
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 1
103404 • WASHER, Lock 5/16 1
24 700344 PIN, Turret lower parallel 4
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 1
103404 • WASHER, Lock 5/16 1
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-5. BOOM ASSEMBLY
FEB. 2000
To Next Page
