Skyjack SJKB-40-D - Page 128

SECTION 6, Page 15SJKB-40-D, SJKB-40-D/F
JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-6. JIB LIFT CYLINDER ASSEMBLY
708655 CYLINDER ASSEMBLY, Jib lift -
1 700245 • WELDMENT, Cylinder barrel 1
2 700244 • WELDMENT, Cylinder rod 1
3 700243 • GLAND, Cylinder 1
4 700242 • PISTON, Cylinder 1
*5 700576 • SEAL, Rod 1
*6 700585 • SEAL, Piston 1
*7 700578 • WIPER, Rod 1
8 700575 • NUT, Lock 3/4-10 1
*9 701965 • O-RING, Gland 1
*10 701634 • O-RING, Piston 1
11 700449 • SPACER, Cylinder 1-1/8” x 1-3/4" x 1-5/16" lg. 1
12 708650 • SPACER, Cylinder 1-1/4” x 1-3/4” x 2-3/4” lg. 1
13 100695 • BUSHING, 1” x 1-1/8" x 1-1/2" lg. 2
14 100309 • BUSHING, 1” x 1-1/8" x 1" lg. 2
15 100249 • BUSHING, 1” x 1-1/8" x 3/4" lg. 2
16 701029 VALVE BLOCK, Jib cylinder 1
103884 • BOLT, HHCS 5/16-18 x 2-1/2” lg. 4
103404 • WASHER, Lock 5/16 4
17 700568 VALVE, Counterbalance 2
18 701956 FITTING, Connector #6orb-#4 2
19 701635 O-RING, Valve block 2
20 103136 VALVE, Manual lowering 1
700456 KIT, Seal repair AR
706521 TOOL, Cylinder assembly 2-1/2” -
* Part of Seal Repair Kit.
