SECTION 6, Page 21SJKB-40-D, SJKB-40-D/F
JUN. 1999
700328 CYLINDER ASSEMBLY, Riser lift -
1 700135 • WELDMENT, Cylinder barrel 1
2 700145 • WELDMENT, Cylinder rod 1
3 700329 • GLAND, Cylinder 1
4 700330 • PISTON, Cylinder 1
*5 700571 • SEAL, Rod 1
*6 106225 • SEAL, Piston 1
*7 700573 • WIPER, Rod 1
*8 700574 • WEAR RING, Gland 1
*9 106220 • WEAR RING, Piston 1
10 106230 • NUT, Lock 1-1/4-12 1
*11 701966 • O-RING, Gland 1
*12 701639 • O-RING, Piston 1
13 103216 • BUSHING, 1-1/2” x 1-11/16" x 1-1/2" lg. 6
14 700043 VALVE BLOCK, Riser lift cylinder 1
103865 • BOLT, HHCS 5/16-18 x 2” lg. 4
103404 • WASHER, Lock 5/16” 4
15 707694 PLUG, Cavity C10-2 1
16 700568 VALVE, Counterbalance 1
17 707234 FITTING, Elbow 45° #6orb-#4 2
18 701635 O-RING, Valve block 2
700452 KIT, Seal repair AR
703872 TOOL, Cylinder assembly 3-1/2” -
* Part of Seal Repair Kit.
FIGURE 6-9. RISER LIFT CYLINDER ASSEMBLY
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
