Skyjack SJKB-40-D - Page 136

SECTION 6, Page 23SJKB-40-D, SJKB-40-D/F
JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-10. ROTARY ACTUATOR ASSEMBLY
706017 ACTUATOR ASSEMBLY, Rotary -
1 701498 • ACTUATOR ROTARY, Keyed 1
701875 • • KIT, Seal repair AR
103024 • • HOSE CLAMP, G8-single 2
104000 • • WASHER, Lock 1/4 1
103632 • • SCREW, Self tapping 1/4-14x3/4” lg. 1
2 100309 • BUSHING 16DU16 2
3 700390 • MANIFOLD, Rotary Actuator 1
709835 • • BOLT, HHCS 1/4-20x1-5/8” lg. 3
4 701487 • SEAL, O-Ring 2-012 2
5 701850 • FITTING, #4orb-#4 2
6 700568 • VALVE, Counterbalance 2
7 700432 • PIN, Slave cylinder 1
103873 • • Bolt, HHCS 3/8-16x2-1/2 lg. 1
104606 • • NUT, Lock 3/8-16 1
8 700376 • WASHER, Bronze 1-3/4” OD x 1” ID 1
9 700434 • SPACER, Actuator pin 1
10 700375 • WELDMENT, Actuator bracket 1
704101 • • HOSE CLAMP, 7/8” 1
104000 • • WASHER, Lock 1/4 1
103632 • • SCREW, Self tapping 1/4-14x3/4” lg. 1
11 706002 • CYLINDER ASSEMBLY, Slave 1
(For components refer to Figure 6-11.)
12 700386 • PIN, Jib Actuator bracket 2
103887 • • BOLT, HHCS 5/16-18x3/4” lg. 1
103404 • • WASHER, Lock 5/16 1
