FIGURE 6-12. BOOM ASSEMBLY (Main and Telescopic Section)
704983 MAIN BOOM ASSEMBLY -
1 704677 • CABLE, 36 Conductor control 660”
2 700367 • PIN, Telescopic Cylinder - Barrel end 1
700781 • • BOLT, HHCS 5/16-18 x 3/8” lg. 1
103984 • • NUT, Lock 5/16-18 1
3 704457 • MAIN BOOM WELDMENT 1
4 700368 • PIN, Telescopin cylinder - rear 1
700781 • • BOLT, HHCS 5/16-18 x 3/8” lg. 1
103404 • • WASHER, Lock 5/16 1
5 706160 • TRACK SUPPORT, Outer boom 1
6 704940 • TRACK SUPPORT WELDMENT, Lower 1
700584 • • BOLT, BHCS 1/4-20 x 1/2” lg. 4
700583 • • NUT, Lock 1/4-20 4
103404 • • WASHER, Lock 5/16 4
700583 • • NUT, Lock 1/4-20 3
7 704738 • BOOM TRACK BRACKET WELDMENT, Outer 1
700583 • • NUT, Lock 1/4-20 3
700584 • • BOLT, BHCS 1/4-20 x 1/2” lg. 4
103980 • • NUT, HEX 1/4-20 4
8 704263 • HOSE GUIDE, Lower 1
9 706162 • HOSE COVER, Main boom 2
700583 • • NUT, Lock 1/4-20 2
10 704431 • BOOM TRAY COVER, Outer 1
700583 • • NUT, Lock 1/4-20 2
11 700935 • BOOM WELDMENT, Telescopic 1
12 706192 • CABLE CARRIER-E-CHAIN ASSEMBLY 1
13 706001 • CYLINDER ASSEMBLY, Telescopic 1
(For components refer to Figure 6-13.)
14 105269 • CABLE, 14/3 Cabtire 732”
15 700370 • PIN SPACER, Telescopic Cylinder 1-3/4 x 7/8” 2
16 700160 SWITCH, Sealed limit 1
700549 • BOLT, Rnd-hd #10-32 x 3/4” lg. 2
104694 • WASHER, Flat #10 2
104185 • WASHER, Lock #10 2
17 (Ref.) • WEAR PADS, Telescopic Boom -
(For components refer to Figure 6-14.)
18 (Ref.) • WEAR PADS, Main Boom -
(For components refer to Figure 6-15.)
