FIGURE 6-13. BOOM TELESCOPING CYLINDER ASSEMBLY
700871 CYLINDER ASSEMBLY, Boom telescopic -
1 700872 • WELDMENT, Cylinder barrel 1
2 700874 • WELDMENT, Cylinder rod 1
3 700359 • GLAND, Cylinder 1
4 700360 • PISTON, Cylinder 1
*5 700576 • SEAL, Rod 1
*6 700577 • SEAL, Piston 1
*7 700578 • WIPER, Rod 1
*8 110949 • WEAR RING, Piston 1
9 700575 • NUT, Lock 3/4-10 1
*10 701964 • O-RING, Gland 1
*11 701634 • O-RING, Piston 1
12 700876 • SPACER, Cylinder 1-1/4” x 1-1/2" x 2.113" lg. 1
13 100309 • BUSHING, 1” x 1-1/8" x 1" lg. 4
14 100695 • BUSHING, 1” x 1-1/8" x 1-1/2" lg. 2
15 700258 SUPPORT ASSEMBLY, Telescopic cylinder 1
700260 • PAD, Telescopic cylinder support 2
700259 • BRACKET, Telescopic cylinder support 1
700581 • BOLT, Soc-hd 1/4-20 x 1-1/2” lg. 2
700582 • BOLT, Flat-hd 1/4-20 x 3/4” lg. 4
NOTE - Items 16 thru 22 are for machines with S/N 95210 and above.
16 709824 VALVE BLOCK, Telescopic cylinder 1
707809 • BOLT, HHCS 5/16-18 x 3” lg. 4
103404 • WASHER, Lock 5/16” 4
17 700568 VALVE, Counterbalance 1
18 710264 VALVE, Counterbalance 1
19 709825 VALVE, Check 1
20 709826 VALVE, Pilot check 1
21 701635 O-RING, Valve block 2
22 701956 FITTING, Connector #6orb-#4 2
NOTE - Items 21 thru 24 are for machines with S/N 95209 and below.
23 700041 VALVE BLOCK, Telescopic cylinder 1
108429 • BOLT, SHCS 5/16-18 x 3-1/2” lg. 4
103404 • WASHER, Lock 5/16” 4
24 700568 VALVE, Counterbalance 2
700455 KIT, Seal repair AR
706522 TOOL, Cylinder assembly 2” -
* Part of Seal Repair Kit.
