FIGURE 6-16. HYDRAULIC HOSE CONNECTIONS - Boom Assembly
1 (Ref.) MANIFOLD ASSEMBLY, Main 1
(For components, refer to Figure 6-22.)
2 707104 HOSE ASSEMBLY, Manifold to master cylinder (H104 0146 00-0) 2
3 707105 HOSE ASSEMBLY, Manifold to lift cylinder (H304 0143 00-0) 2
4 707810 HOSE ASSEMBLY, Master cylinder to slave cylinder (H104 0370 00-0) 2
5 707811 HOSE ASSEMBLY, Manifold to telescopic cylinder (H104 0166 00-0) 2
6 707812 HOSE ASSEMBLY, Union to jib cylinder (H104 0286 00-0) 2
7 707813 HOSE ASSEMBLY, Manifold to union (H104 0196 00-0) 4
8 707814 HOSE ASSEMBLY, Union to rotary actuator (H604 0327 00-0) 2
9 706559 HOSE ASSEMBLY, Manifold to riser cylinder (H104 0024 00-0) 2
10 701498 ACTUATOR, Rotary 1
11 700328 CYLINDER ASSEMBLY, Riser lift 1
(For components, refer to Figure 6-9.)
12 700333 CYLINDER ASSEMBLY, Platform leveling master 1
(For components, refer to Figure 6-7.)
13 700989 CYLINDER ASSEMBLY, Boom lift 1
(For components, refer to Figure 6-8.)
14 700871 CYLINDER ASSEMBLY, Telescopic 1
(For components, refer to Figure 6-13.)
15 700241 CYLINDER ASSEMBLY, Jib lift 1
(For components, refer to Figure 6-6.)
16 700388 CYLINDER ASSEMBLY, Platform leveling slave 1
(For components, refer to Figure 6-11.)
17 701999 FITTING, Elbow 90° #6orb-#4 14
18 703223 FITTING, Tee #6 female-#4-#4 2
19 702124 FITTING, Union #4-#4 4
20 701850 FITTING, Elbow 90° #4orb-#4 2
21 707234 FITTING, Elbow 45° #6orb-#4 4
22 701956 FITTING, Connector #6orb-#4 4
23 103069 FITTING, Connector #6orb-#6 2
NOTE: Refer to Standard Hose Numbering System
(SECTION 5, Page 30) for explanation of hose
numbering.
