SECTION 6, Page 35SJKB-40-D, SJKB-40-D/F JUN. 1999
FIGURE 6-17. TURRET ASSEMBLY
1 704159 WELDMENT, Turret 1
103895 • BOLT, HHCS 5/8-11 x 3” lg. grade 8 18
700782 • WASHER, Flat SAE 5/8” hard-yellow zinc 18
2 700482 BUSHING, 1-1/2” x 1-11/16” x 1/2” lg. 4
3 700483 BUSHING, 1-1/2” x 1-11/16” x 1-1/4” lg. 4
4 707123 MOUNTING PLATE 1
103473 • BOLT, HHCS 3/8-16 x 1” lg. 2
103999 • WASHER, Lock 3/8” 2
5 707678 THROTTLE CONTROL, Kabota Engine (Barber Colman) 1
701643 THROTTLE CONTROL, Ford Engine (Barber Colman) 1
104698 • BOLT, Machine head #10-32 x 3/4” lg. 4
104185 • WASHER, Lock #10 4
104003 • NUT, Hex #10-32 4
6 707884 COVER, Barber Colman 1
7 707627 ASSEMBLY, Fuel tank (For components, refer to Figure 6-19.) 1
103845 • BOLT, HHCS 5/16-18 x 1/2” lg. 4
103996 • WASHER, Flat 5/16” SAE 4
103404 • WASHER, Lock 5/16” 4
8 706079 ASSEMBLY, Hydraulic tank (For components, refer to Figure 6-20.) 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. 3
700522 • BOLT, SHCS 3/8-16 x 2” lg. 3
103472 • WASHER, Flat 3/8” SAE 6
103999 • WASHER, Lock 3/8” 3
104606 • NUT, Lock 3/8” 3
9 703719 BATTERY, 12 Volt 850 CCA 1
706602 TERMINAL COVER, Red 1
10 707275 PLATE, Battery hold down 1
707298 • BOLT, HHCS 3/8-16 x 8” lg. 2
11 704344 ASSEMBLY, Rotary Manifold (For components, refer to Figure 6-21.) 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. 3
103472 • WASHER, Flat 3/8” SAE 3
103999 • WASHER, Lock 3/8” 3
702195 • BOLT, HHCS 3/8-16 x 1 1/2” lg. 2
702929 • NUT, Hex jam 3/8-16 2
12 708861 SWITCH, Tilt 1
103855 • BOLT, HHCS 1/4-20 x 1/2” lg. 4
104000 • WASHER, Lock 1/4” 4
13 704269 ASSEMBLY, System manifold (For components, refer to Figure 6-22.) 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. 4
103472 • WASHER, Flat 3/8” SAE 4
103999 • WASHER, Lock 3/8” 4
14 704968 VALVE ASSEMBLY, Proportional control 1
707825 • VALVE 1
703803 • COIL 1
103860 • BOLT, HHCS 1/4-20 x 1-3/4” lg. 2
103995 • WASHER, Flat 1/4” SAE 2
700583 • NUT, Lock 1/4-20 2
701956 • FITTING, Connector #6orb - #4 2
15 706921 PUMP/MOTOR ASSEMBLY, Emergency lowering 1
• PUMP, Emergency lowering 1
• MOTOR, Emergency lowering 1
• COUPLER 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. 2
103999 • WASHER, Lock 3/8” 2
110669 • FITTING, Elbow 90° #6orb - #8 1
701998 • FITTING, Elbow 90° #8orb - #8 1
16 (Ref.) ASSEMBLY, Brake manifold (For components, refer to Figure 6-23.) 1
702812 • BOLT, HHCS 3/8-16 x 4-1/2” lg. 2
103999 • WASHER, Lock 3/8” 2
17 704287 ASSEMBLY, Speed reducer (For components, refer to Figure 6-24.) 1
706403 • SET SCREW, 1/2-13 x 2-1/2” lg. 6
103471 • NUT, Hex 1/2-13 6
706429 • BOLT, SHCS 5/8-11 x 2” lg. 4
103998 • WASHER, Lock 5/8” 4
Parts List Continued on Page 37.
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
To Next Page
