FIGURE 6-17. TURRET ASSEMBLY
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
Parts List Continued from Page 35.
18 706360 ECCENTRIC RING 1
19 704666 MANIFOLD ASSEMBLY, Low speed/torque 1
708336 • RELIEF VALVE 1
708332 • VALVE 1
708331 • COIL 1
701206 • BOLT, HHCS 1/4-20 x 2-1/4” lg. 2
104000 • WASHER, Lock 1/4” 2
701999 • FITTING, Elbow 90° #6orb - #4 2
20 708600 SWITCH, Sealed limit 1
700549 • BOLT, SHCH #10-32 x 3/4” lg. 2
104694 • WASHER, Flat #10 2
104185 • WASHER, Lock #10 2
104003 • NUT, Hex #10-32 2
21 704476 OIL FILTER, High pressure 1
704559 • ELEMENT, High pressure filter 1
704581 • BOLT, HHCS 1/4-20 x 4 1/2” lg. 2
700583 • NUT, Lock 1/4-20 2
707280 • FITTING, Connector #12orb - #8 2
706715 • FITTING, Swivel nut tee #8 - #8 - #8 1
703046 • FITTING, Tube reducer #6orb - #8 1
702761 • FITTING, Swivel nut elbow 90° #6 - #6 (Ford 1.3 Only) 1
702813 • FITTING, Swivel nut elbow 45° #8 - #8 (Ford 1.3 Only) 1
22 700814 PAD, Boom guide, 1” x 2-1/2” x 3-1/4” 2
23 700813 PAD, Boom lower rest 2
709832 • BOLT, HHCS 3/8-16 x 2”, grade 5 2
103999 • WASHER, Lock 3/8” 2
24 (Ref.) PANEL ASSEMBLY, Turret control (For components, refer to Figure 6-25.) 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. 4
103472 • WASHER, Flat 3/8” SAE 4
103999 • WASHER, Lock 3/8” 4
25 706833 CHECK VALVE, In line 1
707809 • BOLT, HHCS 5/16-18 x 3” lg. 1
103984 • NUT, Lock 5/16-18 1
702116 • FITTING, Connector #8orb - #8 1
707995 • FITTING, Branch tee #8orb - #8 1
26 703658 PIN, Hitch 3/8” (SJKB-40-D, -40-D/F Kabota engine only) 1
27 707774 LANYARD, 8” lg. (SJKB-40-D, -40-D/F Kabota engine only) 1
103996 • WASHER, Flat 5/16” SAE 2
103984 • NUT, Lock 5/16-18 1
28 706372 PIN, Transportation lock 1
29 703658 PIN, Hitch 3/8” 1
30 105807 LANYARD, 6” lg. 1
101632 • BOLT, HHCS 3/8-16 x 3/4” lg. 1
103472 • WASHER, Flat 3/8” SAE 1
31 102600 SWITCH, Main disconnect 1
706528 • COVER, Terminal 1
706529 • COVER, Terminal 1
32 108714 KIT, Lever lockout 1
33 707122 MOUNTING PLATE, Battery disconnect 1
34 700903 ACCUMULATOR 1
700904 • CLAMP, Accumulator 1
103855 • BOLT, HHCS 1/4-20 x 1/2” lg. 2
104000 • WASHER, Lock 1/4” 2
708517 • FITTING, Swivel adapter #8orb - #8 1
708519 • FITTING, Branch tee #8 - #8 - #8 1
708518 • FITTING, Pipe adapter #8 - #4 1
114520 • FITTING, Quick disconnect 1
114521 • FITTING, Dust cap 1
35 704949 • VALVE, Shuttle cartrifge 1
701850 • • FITTING, Elbow 90° #4orb - #4 2
701954 • • FITTING, Connector, #4orb - #4 1
