Skyjack SJKB-40-D - Page 156

SECTION 6, Page 43SJKB-40-D, SJKB-40-D/F JUN. 1999
FIGURE 6-21. ROTARY MANIFOLD ASSEMBLY
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
704344 ASSEMBLY, Rotary manifold -
1 704343 • MANIFOLD, Rotary 1
2 704739 • WELDMENT, Rotary manifold mounting plate 1
101632 • • BOLT, HHCS 3/8-16 x 3/4” lg. 6
103999 • • WASHER, Lock 3/8” 6
3 706294 • SWITCH, Directional sensing limit 1
105621 • • BOLT, Machine head #10-32 x 1” lg. 2
104694 • • WASHER, Flat #10 2
104185 • • WASHER, Lock #10 2
104003 • • NUT, Hex #10-32 2
4 706332 • PLATE, Limit switch mounting 1
105621 • • BOLT, Machine head #10-32 x 1” lg. 2
104694 • • WASHER, Flat #10 2
104185 • • WASHER, Lock #10 2
104003 • • NUT, Hex #10-32 2
5 702118 • FITTING, Connector #12orb - #12 3
6 702119 • FITTING, Elbow 90° female-#12 - #12 3
7 701956 • FITTING, Connector-#6orb - #4 2
8 103069 • FITTING, Connector #6orb - #6 1
9 104437 • FITTING, Plug #6 2
10 103073 • FITTING, Elbow 90° #6orb - #6 1
11 701999 • FITTING, Elbow 90° #6orb - #4 2
12 702117 • FITTING, Elbow 90° #12orb - #12 3
NOTE - Items 13 thru 17 are for machines with
Dual Fuel Option only.
13 702820 • FITTING, Adaptor 3/4NPT - 1/4NPT 1
14 709204 • FITTING, Pipe nipple 1/4NPT x 4” lg. 1
15 702500 • FITTING, Elbow 90° female 1/4NPT - 1/4NPT 1
16 702821 • FITTING, Adaptor 3/4NPT - 3/8NPT 1
17 702239 • FITTING, Brass swivel #6orb - #4 1
