SJKB-40-D, SJKB-40-D/F SECTION 6, Page 67
JUN. 1999
FIGURE 6-31. TURRET HYDRAULIC CONNECTIONS
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
1 706079 ASSEMBLY, Hydraulic tank 1
2 704344 ASSEMBLY, Rotary manifold 1
3 704269 ASSEMBLY, System manfold 1
4 704968 VALVE ASSEMBLY, Proportional control 1
5 704720 ASSEMBLY, Brake manifold 1
6 706921 PUMP/MOTOR ASSEMBLY, Emergency lowering 1
7 704287 ASSEMBLY, Speed reducer 1
8 704666 MANIFOLD ASSEMBLY, Low speed/torque 1
9 704476 OIL FILTER, High pressure 1
10 706833 CHECK VALVE, In line 1
11 703693 PUMP, Hydraulic drive 1
12 704957 PUMP, Hydraulic system 1
13 702031 COOLER, Oil 1
14 706814 OIL FILTER, Medium pressure 1
15 704949 VALVE, Shuttle cartridge 1
16 700903 ACCUMILATOR 1
17 707117 FITTING, Elbow 45° #12NPT - #16 1
18 707116 FITTING, Elbow 45° #12NPT - #12 1
19 706137 FITTING, Elbow 45° #12NPT - #8 1
20 702541 FITTING, Elbow 90° #12NPT - #12 2
21 707120 FITTING, Connector #12 - #8 1
22 703118 FITTING, Connector #6NPT - #6 1
23 702118 FITTING, Connector #12orb - #12 3
24 702119 FITTING, Elbow 90° female-#12 - #12 3
25 103069 FITTING, Connector #6orb - #6 1
26 701956 FITTING, Connector #6orb - #4 7
27 701999 FITTING, Elbow 90° #6orb - #4 6
28 110669 FITTING, Elbow 90° #6orb - #8 3
29 707742 FITTING, Elbow 45° #6orb - #6 1
30 701954 FITTING, Connector #4orb - #4 (Ford 1.3 Only) 1
31 706715 FITTING, Swivel nut tee #8 - #8 - #8 2
32 702116 FITTING, Connector #8orb - #8 1
33 707280 FITTING, Connector #12orb - #8 2
34 707995 FITTING, Branch tee #8orb - #8 1
35 704582 FITTING, Connector #10orb - #12 2
36 707036 FITTING, Split flange #12 - #12 2
37 702233 KIT, Split flange seal 2
38 707040 FITTING, Elbow 90° #16orb -#16 1
39 707041 FITTING, Reducer #4 - #6 1
40 704492 FITTING, Elbow 90° #10orb - #6 1
41 701850 FITTING, Elbow 90° #4orb - #4 4
FITTING, Elbow 90° #4orb - #4 (Ford 1.3 Only) 3
42 703255 FITTING, Extra long elbow 90° #8orb - #6 1
43 707039 FITTING, Extra long elbow 90° #4orb - #4 1
44 103070 FITTING, Connector #8orb - #6 1
45 702119 FITTING, Elbow 90° swivel #12 -#12 3
46 703533 FITTING, Elbow 90° #10orb - #8 1
47 701879 FITTING, Connector, #16 - #12 2
48 109052 FITTING, Connector #12orb - #6 2
49 707234 FITTING, Elbow 45° #6orb - #4 1
50 707996 FITTING, Connector #10orb - #4 2
51 701998 FITTING, Elbow 90° #8orb - #8 1
52 707829 HOSE ASSEMBLY, (H108 0047 00-0) 1
53 708322 HOSE ASSEMBLY, (H612 0046 00-0) 1
54 708327 HOSE ASSEMBLY, (H2516 0040 00-0) 1
55 707831 HOSE ASSEMBLY, (H112 0089 00-0) 1
708348 HOSE ASSEMBLY, (H112 0103 00-0)(Ford Engine Only) 1
56 706577 HOSE ASSEMBLY, (H612 0031 00-0) 1
57 707828 HOSE ASSEMBLY, (H108 0033 00-0) 1
58 708328 HOSE ASSEMBLY, (H106 0023 00-00 1
59 707840 HOSE ASSEMBLY, (H608 0029 00-0) 1
60 707841 HOSE ASSEMBLY, (H108 0028 00-0) 2
61 706568 HOSE ASSEMBLY, (H104 0013 00-0) 2
62 707838 HOSE ASSEMBLY, (H604 0043 00-0) 2
63 707832 HOSE ASSEMBLY, (H304 0046 00-0) 1
64 706556 HOSE ASSEMBLY, (H304 0043 00-0) 1
65 707834 HOSE ASSEMBLY, (H506 0034 00-0) 1
66 708326 HOSE ASSEMBLY, (H2412 0055 00-0) 2
708353 HOSE ASSEMBLY, (H1912 0055 00-0)(Ford Engine Only) 2
67 708325 HOSE ASSEMBLY, (H2204 0056 00-0) 1
708352 HOSE ASSEMBLY, (H2204 0030 00-0)(Ford Engine Only) 1
68 707830 HOSE ASSEMBLY, (H512 0038 00-0) (Diesel) 1
707836 HOSE ASSEMBLY, (H512 0033 00-0) (Kabota-Dual Fuel) 1
709399 HOSE ASSEMBLY, (H512 0041 00-0)(Ford-Dual Fuel) 1
69 707827 HOSE ASSEMBLY, (H108 0014 00-0) 1
70 707835 HOSE ASSEMBLY, (H508 0038 00-0) 1
71 708323 HOSE ASSEMBLY, (H2104 0021 00-0) 1
708350 HOSE ASSEMBLY, (H2204 0038 00-0)(Ford Engine Only) 1
72 708324 HOSE ASSEMBLY, (H2204 0012 00-0) 1
708351 HOSE ASSEMBLY, (H2204 0036 00-0)(Ford Engine Only) 1
73 707826 HOSE ASSEMBLY, (H106 0035 00-0) 1
HOSE ASSEMBLY, (H606 0050 00-0)(Ford Engine Only) 1
74 707839 HOSE ASSEMBLY, (H606 0042 00-0) 1
704530 HOSE ASSEMBLY, (H6060050 00-0)(Ford Engine Only) 1
75 707837 HOSE ASSEMBLY, (H604 0021 00-0) 1
76 707085 HOSE ASSEMBLY, (H104 0015 02-0 1
77 708969 HOSE ASSEMBLY, (H106 0028 00-0)(Ford 1.3 Only) 1
78 103069 FITTING, Connector #6orb - #6 2
707742 FITTING, Elbow 45° #6orb - #6 (Ford 1.3 Only) 2
79 703046 FITTING, Tube reducer #6orb - #8 1
80 708517 FITTING, Swivel adapter #8orb - #8 1
81 708519 FITTING, Branch tee #8 #8 #8 1
82 708518 FITTING, Pipe adapter #8 #4 1
83 114520 FITTING, Quick disconnect 1
84 702761 FITTING, Swivel nut elbow 90° #6 - #6 (Kubota Diesel Only) 1
85 702761 FITTING, Swivel nut elbow 90° #6 - #6 (Ford 1.3 Only) 1
86 702813 FITTING, Swivel nut elbow 45° #8 - #8 (Ford 1.3 Only) 1
NOTE: Refer to Standard Hose Numbering System
(SECTION 5, Page 30) for explanation of hose numbering.
