Skyjack SJKB-40-D - Page 182

SECTION 6, Page 69
SJKB-40-D,SJKB-40-D/F
JUN. 1999
Index
No.
Skyjack
Part No.
Description
1 2 3 4 5 6 7
Units
per
Assy.
FIGURE 6-32. BASE, AXLES, AND WHEELS (Standard 4x2)
1 704150 WELDMENT, Base 1
2 706991 COVER PLATE, Axle 1
101632 • BOLT, HHCS 3/8-16 x 3/4 lg. Grade 8 4
103472 • WASHER, Flat SAE 3/8” 4
103999 • WASHER, Lock 3/8” 4
3 700536 AXLE MOUNT PLATE, Bottom 2
704844 • BOLT, HHCS 3/4-10 x 8” lg. Grade 8 4
700575 • NUT, 3/4-10 Grade C Top Lock 4
4 703661 GEAR, Turret rotate 1
701762 • BOLT, HHCS 5/8-11 x 4-1/2” Grade 8 20
700782 • WASHER, Flat SAE 5/8” hard 20
708304 • FITTING, 90° Grease zerk 1
5 704145 DRIVE AXLE ASSEMBLY 1
(For components, refer to Figure 6-38.)
6 707022 GUARD WELDMENT, Brake fitting 2
7 701094 STEERING ASSEMBLY, Right 1
(For components, refer to Figure 6-37.)
8 700291 KING PIN, Spindle 2
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 2
103404 • WASHER, Lock 5/16 2
103216 • BUSHING 1-1/2” x 1-11/16” x 1-1/2” lg. 2
9 700262 THRUST BEARING 2
10 704146 STEERING ASSEMBLY, Left 1
(For components, refer to Figure 6-37.)
11 700693 TIE BAR WELDMENT 1
12 700297 PIN, Tie bar 2
703016 • BOLT, HHCS 5/16-18 x 5/8” lg. 2
103404 • WASHER, Lock 5/16 2
13 103216 BUSHING 1-1/2” x 1-11/16” x 1-1/2” lg. 4
14 700783 STEER CYLINDER ASSEMBLY 1
(For components, refer to Figure 6-36.)
15 700312 PIN, Steer cylinder 2
103887 • BOLT, HHCS 5/16-18 x 3/4” lg. 2
103404 • WASHER, Lock 5/16 2
16 700314 BUSHING, Spacer 4
17 701061 WHEEL ASSEMBLY, Standard 10 x 16.5 4
701062 • RIM 1
104088 • VALVE 1
709347 • TIRE 1
702030 WHEEL/TIRE ASSEMBLY, 10 x 16.5 Lug, foam filled (option) 4
701672 WHEEL/TIRE ASSEMBLY, 31 x 15.5 Lug, flotation (option) 4
NOTE - Items 18 thru 19 are for machines with
Dual Fuel Option only.
18 702633 BRACKETS, LP 1
19 702253 LP TANK, 43.5 lb. 240PSI 1
704547 HOSE ASSEMBLY, LP 1
702236 FITTING, LP 3400-4 1
103006 FITTING, LP - Female tank 1
