SECTION 2, Page 12 SJKB-40-D, SJKB-40-D/F
JUN. 1999
Mt40-204
Table 2-5. General Specifications
NOTE: For additional specifications, refer to Section 1.
Table 2-6. Standard Operating Times
Mt40-205
TIRES Refer to Table 2-3.
INSIDE TURNING RADIUS (4x2) 7’ 0" (2.13m)
INSIDE TURNING RADIUS (4x4) 11’ 6" (3.5m)
OUTSIDE TURNING RADIUS (4x2) 14’ 6" (4.42m)
OUTSIDE TURNING RADIUS (4x4) 16’ 10" (5.13m)
UNDERCLEARANCE (4x2) 8.5" (21.6cm)
UNDERCLEARANCE (4x4) 8.5" (21.6cm)
WHEELBASE 6.3" (1.9m)
FLOOR LOADING 34 psi(2.39 kg/cm²)
TAILSWING AT PIVOTAL HEIGHT ZERO
TURRET ROTATION continuous
MECHANICAL IDLE STOP (Dual fuel Only)
ENGINE RPM SETTING (Dual Fuel)
ENGINE RPM SETTING (Diesel & Ford 1.3)
950
1400(idle),2200,3350
1400(idle),1800,3000
ELECTRICAL SYSTEM (engine) 12 VDC
BATTERY (engine) 12 Volt, 850 CCA
LIFT TIME (minimum)(entry height to maximum platform height) 124 Seconds
LOWERING TIME (minimum)(maximum platform height to entry height) 92 Seconds
SYSTEM RELIEF PRESSURE (R1) 2600 psi
TRAVEL SPEED (maximum at stowed height) 3.0 mph (4.8kph)
TRAVEL SPEED (maximum at elevated height) 0.8mph (1.3kph)
HYD-RESERVOIR CAPACITY 45 gal. (170 ltr.)
HYD-SYSTEM CAPACITY 54 gal. (203.8 ltr.)
FUEL TANK CAPACITY 15 gal. (56.8 ltr.)
AMBIENT NOISE LEVEL 85 db
FUNCTION TEST SECONDS
Riser Up 32-36
Riser Down 24-26
Boom Up 24-26
Boom Down 16-18
Boom Extend (S/N 95210 and above.) 12-16
Boom Extend (S/N 95209 and below.) 30-34
Boom Retract 20-22
Jib Up 12-14
Jib Down 10-12
Platform Rotate Left 7-9
Platform Rotate Right 7-9
Turret Rotate Clockwise 57-63
Turret Rotate Counter Clockwise 57-63
