Skyjack SJKB-40-D - Page 48

SJKB-40-D, SJKB-40-D/F
SECTION 3, Page 25
JUNE 1999
FIGURE 3-13. HYDRAULIC SCHEMATIC PARTS LIST
1 2 3 4 5 6 7
Ref.
No.
Skyjack
Part No.
Description
Units
per
Assy
2H-12 704968 VALVE, Proportional flow control 1
2H-21A 700677 VALVE, Dump 1
2H-28B 703190 VALVE, 5° Brake 1
2H-59 708332 VALVE, High speed drive 1
3H-26B 703189 VALVE, Brake 1
4H-13A 704822 VALVE, Riser down 1
4H-14A 704822 VALVE, Riser up 1
4H-15 $ VALVE, Reverse drive 1
4H-16 $ VALVE, Forward drive 1
4H-23A 704821 VALVE, Right steer 1
4H-24A 704821 VALVE, Left steer 1
4H-30A 704822 VALVE, Boom down 1
4H-31A 704822 VALVE, Boom up 1
4H-32A 704822 VALVE, Turret rotate clockwise 1
4H-33A 704822 VALVE, Turret rotate c-clockwise 1
4H-34A 704822 VALVE, Jib down 1
4H-35A 704822 VALVE, Jib up 1
4H-36A 704822 VALVE, Rotate left 1
4H-37A 704822 VALVE, Rotate right 1
4H-38A 704822 VALVE, Telescope retract 1
4H-39A 704822 VALVE, Telescope extend 1
4H-40A 704822 VALVE, Platform level down 1
4H-41A 704822 VALVE, Platform level up 1
AC1 700903 ACCUMULATOR, Pressure 1
BP-1 $ VALVE, Shuttle 1
C1 700328 CYLINDER ASSEMBLY, Riser lift 1
700452 KIT, Seal repair AR
C2 700989 CYLINDER ASSEMBLY, Boom lift 1
700453 KIT, Seal repair AR
C3 700871 CYLINDER ASSEMBLY, Boom Telescope 1
700455 KIT, Seal repair AR
C4 700241 CYLINDER ASSEMBLY, Jib lift 1
700456 KIT, Seal repair AR
C5 700333 CYLINDER ASSEMBLY, Platform leveling master 1
700454 KIT, Seal repair AR
C6 700388 CYLINDER ASSEMBLY, Platform leveling slave 1
700454 KIT, Seal repair AR
C7 700783 CYLINDER ASSEMBLY, Steering 1
701076 KIT, Seal repair AR
CB01-09 700568 VALVE, Counter balance 9
CB10-11 706384 VALVE, Counter balance 2
CB12-13 700670 VALVE, Counter balance 2
CV1 706833 VALVE, Check 1
DCM1 706921 PUMP/MOTOR ASSEMBLY, Emergency 1
F1 706814 FILTER, Medium pressure 1
708333 ELEMENT, Filter 1
F2 704476 FILTER, High pressure 1
704559 ELEMENT, Filter 1
FC1 700763 VALVE, Turret rotation speed control 1
FC2 706026 VALVE, Needle 1
G1 703725 GAUGE, Pressure (800 PSI) 1
1 2 3 4 5 6 7
Ref.
No.
Skyjack
Part No.
Description
Units
per
Assy
HP1 703193 VALVE, Brake release hand pump 1
M1 704958 MOTOR, Drive 1
M2 702992 MOTOR, Turret rotation 1
OC1 702031 COOLER, Oil 1
P1 703693 PUMP, Drive (4800 PSI) 1
P2 704957 PUMP, System 1
POR1 710840 VALVE, Pressure override 1
PR1 703191 VALVE, Pressure reducing (600 PSI) 1
RA1 701498 ACTUATOR, Basket rotary 1
701875 • KIT, Seal repair AR
RV1 700673 VALVE, System relief 1
RV2 - 3 700672 VALVE, Relief (1000 PSI) 2
RV4 708336 VALVE, Hi/low drive pilot pressure adjustment (250 PSI) 1
RV5 $ VALVE, Relief (390 PSI) 1
RV6 $ VALVE, Drive relief 1
RV7 $ VALVE, Drive relief 1
RV8 703194 VALVE, Relief (700 PSI) 1
SV1 704949 VALVE, Shuttle 1
SV2 703197 VALVE, Shuttle 1
SV3 703197 VALVE, Shuttle 1
V1 103136 VALVE, Boom emergency lowering 1
V2 103136 VALVE, Jib emergency lowering 1
V3 703192 VALVE, Release override 1
MARCH, 2000
