Table 5-1. Special Tools
Table 5-2. Torque Specifications
Mt40-502
DIRECTIONAL VALVE MOUNTING SCREWS 28-32 in. lbs.
TURRET ROTATE GEAR MOUNTING BOLTS 205 ft. lbs. / Copper based anti-sieze
WHEEL MOUNTING BOLTS (4 x 4) 290 ft. lbs. / Dry
WHEEL MOUNTING BOLTS (4 x 2) 220 ft. lbs. / Dry
COUNTERWEIGHT BOLTS 240 ft. lbs. / Dry
AXLE MOUNTING BOLTS 205 ft. lbs. / Dry
HYDRAULIC PUMP MOUNTING BOLTS 75 ft. lbs. / Dry
SPEED REDUCER MOUNTING BOLTS 175 ft. lbs. / Light oil
CARTRIDGE VALVES
SIZE 08 38 58 10 12 16
ft. lbs. (max) 20 20 20 25 35 50
in. lbs. (max) 240 240 240 300 420 600
COILS
SIZE
ft. lbs. (max) 4 to 5
in. lbs. (max) 48 to 60
SAE PLUGS
SIZE 2 4 5 6 8 10 12 16
ft. lbs.
(max)
3 10 15 15 25 25 30 35
in. lbs.
(max)
36 120 180 180 300 300 360 400
BRAKE ADJUSTMENT TOOL SKYJACK PART 707704
17mm ALLEN WRENCH PURCHASE LOCALLY
PRESSURE GAUGE 0 - 5000 psi PURCHASE LOCALLY
PRESSURE GAUGE 0 - 1000 psi PURCHASE LOCALLY
CYLINDER ASSEMBLY TOOL - 2" Inside Diameter SKYJACK PART 706522
CYLINDER ASSEMBLY TOOL - 2-1/2" Inside Diameter SKYJACK PART 706521
CYLINDER ASSEMBLY TOOL - 3-1/4" Inside Diameter SKYJACK PART 709800
CYLINDER ASSEMBLY TOOL - 3-1/2" Inside Diameter SKYJACK PART 703872
CYLINDER ASSEMBLY TOOL - 4-1/2" Inside Diameter SKYJACK PART 703873
CYLINDER ASSEMBLY TOOL - 5" Inside Diameter SKYJACK PART 706866
SEVCON CALIBRATOR SKYJACK PART 701051
